Yealink CP935W User Manual

Yealink CP965 User Guide
Registering the CPW65 with Another Phone
When you no longer want to register with the current phone, you can register the CPW65 with another phone.
CPW65 can only be registered with one phone at a time, if you register the CPW65 to another phone, the CPW65
will deregister from the previous phone automatically.
Procedure
1. Go to More > MIC.
2. Turn on DECT MIC.
3.
Select to search for CPW65.
4.
Put the CPW65 on the charging cradle or connect to the charging cable and make sure it is charging.
5.
Long tapthe on the CPW65 for 5 seconds.
The CPW65 enters the registration mode. And the mute LED indicator on the CPW65 fast flashes yellow.
The CPW65 registers with the phone automatically.
Unregistering the CPW65
When you no longer need the CPW65 as the external audio input device, you can unregister it.
Procedure
1. Go to More > MIC.
2. Select the desired microphone and then select Detail.
3. Select Unbind.
Muting or Unmuting the CPW65
During the call, you can mute or unmute the CPW65 at any time.
Procedure
1.
Tap to mute the call.
The mute LED indicator glows red. And the icon appears in the status bar of the phone.
92

Yealink CP935W Specifications

General

Control type	Touch
Product type	IP conference phone
Voice codecs	AMR, G.711a, G.722, G.722.1C, G.723, G.726, G.729, G.729A, OPUS, PCMA, iLBC
Product color	Black
Speaker power	5 W
Noise reduction	Yes
Speaker diameter	56 mm
Bluetooth version	4.2
Display resolution	480 x 800 pixels
Phonebook capacity	1000 entries
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	256-bit AES, HTTPS, MD5, SRTP, TLS, WPA2
Microphone pick-up range	6 m
Number of microphone arrays	6
Conference call ways quantity	5
USB version	2.0
USB connector type	USB Type-C
USB ports quantity	1
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Power consumption (max)	6 W
Power consumption (typical)	2.2 W

Weight and Dimensions

Depth	285.2 mm
Width	288.6 mm
Height	63.9 mm
