Yealink CP935W User Manual

Yealink CP935W User Guide
43
3. Enter the multicast IP address and port number (for example, 224.5.6.20:10008) in the Address field.
4. Enter the string that will display on the phone screen in the Label field.
5. Enter the desired channel between 0 and 30 in the Channel field.
6.
Select .
7.
To set more paging groups, repeat steps 2 to 6.
Sending Pages by a Paging List Key
You can send a paging by using the Paging List key when the phone is idle.
Before You Begin
You need to set a Paging List key in advance.
Procedure
1.
Tap the Paging List key when the phone is idle.
2.
Select the desired paging group.
Both your phone and receiver’s phone play a warning tone and the multicast RTP session will be automatically
answered on the receiver’s phone in the speakerphone (hands-free) mode.
Related Topic
Setting a Paging List Key
Deleting a Paging Group
You can delete any group from the paging group list.
Procedure
1.
Tap the Paging List key when the phone is idle.
Go to More > Settings > Features > Paging List.
If the Paging List key is not configured, you can also go to Settings > Features > Paging List to configure the
paging list.
2.
Select after the desired paging group.
3. Select Delete.
The phone prompts you to delete the paging group or not.
4. Select OK.
If you want to delete all paging groups, you can tap on the top-right of the phone screen.
Receiving Multicast Paging
Your system administrator has set a listening paging group for you, you can automatically receive a paging call
when the phone is idle.
When there is a voice call or a paging call in progress, the phone handles the new paging call differently according
to the multicast listening settings configured by your system administrator.
Managing a Paging Call
During a paging call, you can manage it manually at any time.
Procedure
l
Select Hold to place the current paging call on hold.
The paging call is placed on hold and the receiver releases the session.
l
Select Resume to resume the held paging call.

Yealink CP935W Specifications

General

Control type	Touch
Product type	IP conference phone
Voice codecs	AMR, G.711a, G.722, G.722.1C, G.723, G.726, G.729, G.729A, OPUS, PCMA, iLBC
Product color	Black
Speaker power	5 W
Noise reduction	Yes
Speaker diameter	56 mm
Bluetooth version	4.2
Display resolution	480 x 800 pixels
Phonebook capacity	1000 entries
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	256-bit AES, HTTPS, MD5, SRTP, TLS, WPA2
Microphone pick-up range	6 m
Number of microphone arrays	6
Conference call ways quantity	5
USB version	2.0
USB connector type	USB Type-C
USB ports quantity	1
Operating temperature (T-T)	-10 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Power consumption (max)	6 W
Power consumption (typical)	2.2 W

Weight and Dimensions

Depth	285.2 mm
Width	288.6 mm
Height	63.9 mm
