Yealink SIP-T2 User Manual

Administrator’s Guide for SIP-T2 /T3 /T4 /T5 /CP920 IP Phones
265
Programmable Keys Configuration
Supported Programmable Keys
The following tables list programmable keys for each phone model.
Pro-
grammable
Key IDs
CP920
T31P/T31G/T31/T30P/T3-
0/T19(P) E2
T23P/T23G/-
T21(P) E2
T29G/T2-
7G
T53W/T53/T43-
U/
T42G/T42S/T4-
2U/
T41P/T41S
/T40P/T40G/
T33P/T33G
T54W/T48U/T48G/
T48S/T46U/T46S/T-
46G
T57W
1
SoftKe-
y1
SoftKey1 SoftKey1 SoftKey1 SoftKey1 SoftKey1
SoftKe-
y1
2
SoftKe-
y2
SoftKey2 SoftKey2 SoftKey2 SoftKey2 SoftKey2
SoftKe-
y2
3
SoftKe-
y3
SoftKey3 SoftKey3 SoftKey3 SoftKey3 SoftKey3
SoftKe-
y3
4
SoftKe-
y4
SoftKey4 SoftKey4 SoftKey4 SoftKey4 SoftKey4
SoftKe-
y4
5 Up Up Up Up Up Up /
6 Down Down Down Down Down Down /
7 / Left Left Left Left Left /
8 / Right Right Right Right Right /
9 OK OK OK OK OK OK /
10 / / Cancel Cancel Cancel Cancel /
11 / / / CONF / / /
12 / / / HOLD / HOLD HOLD
13 MUTE MUTE / MUTE MUTE MUTE MUTE
14 / TRAN TRAN TRAN / TRAN TRAN
17 / Redial Redial Redial Redial Redial Redial
18 / Message Message Message Message Message
Mes-
sage
Programmable Keys Configuration
For T23P/T23G/T21(P) E2 phones, Cancel key can be configured only when “features.keep_mute.enable” is set to
0 (Disabled).
For other phones, Mute key can be configured only when “features.keep_mute.enable” is set to 0 (Disabled).
The following table lists the parameters you can use to configure programmable keys.
Parameter
programablekey.type_range.custom <y0000000000xx>.cfg
Description
It configures the list for available programmable key types when configuring programmable keys.
To assign function types, specify programmable key type IDs which start with or without a symbol ”+”.
For example, “+2,15,16,7,4” or “2,15,16,7,4” means only “N/A”, “Forward”, “Line”, “BLF”, “Recall”,
