Yealink SIP-T53W Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
196
Customizing a Language Pack for Note Display
When you add a new language pack for the note, the note language pack must be formatted as “X.name_note.xml”
(X starts from 14, “name” is replaced with the language name). If the note language name is the same as the exist-
ing one, the new uploaded note language pack will override the existing one. We recommend that the filename of
the new note language pack should not be the same as the existing one.
Procedure
Open the desired note language template pack (for example, 1.English_note.xml) using an XML editor.
Modify the text of the note field. Do not modify the note name.
The following shows a portion of the note language pack “1.English_note.xml” for the web user interface:
Save the note language pack and place it to the provisioning server.
Custom Language for Web and Note Display Configuration
If you want to add a new language (for example, Wuilan) to phones, prepare the language file named as
“14.Wuilan.js” and “14.Wuilan_note.xml” for downloading. After the update, you will find a new language selection
“Wuilan” at the top-right corner of the web user interface, and new note information is displayed in the icon when
the new language is selected.
The following table lists the parameters you can use to configure a custom language for web and note display.
Parameter
wui_lang.url <y0000000000xx>.cfg
Description
It configures the access URL of the custom language pack for the web user interface.
Permitted
Values
URL within 511 characters
For example http://localhost/X.GUI.name.lang
X starts from 014, “name” is replaced with the language name
Default
Blank
Parameter
wui_lang_note.url <y0000000000xx>.cfg
Description
It configures the access URL of the custom note language pack for the web user interface.
Permitted
Values
URL within 511 characters
For example http://localhost/X.name_note.xml

Yealink SIP-T53W Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP mobile phone
Product color	Gray
Keypad illumination	Yes
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Security algorithms	AES, HTTPS, SIPS
Networking standards	IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Lines quantity	8 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.3 W
Volume control	Buttons
Number of programmable keys	8
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Number of DECT wireless handsets	4
Voice codecs	G.722, G.723.1, G.726, G.729A, G.729B, OPUS, iLBC

Weight and Dimensions

Depth	210.6 mm
Width	212 mm
Height	174.5 mm
