Yealink SIP-T53W Administrator's Guide

General Features
498
Reboot in Talking Configuration
The following table lists the parameter you can use to configure the reboot in talking.
Parameter
features.reboot_in_talk_enable <y0000000000xx>.cfg
Description
It enables or disables the phone to reboot during a call when it receives a reboot Notify message.
Permitted
Values
0-Disabled
1-Enabled
Default
0
Web UI
Features > General Information > Reboot in Talking
Reserve # in User Name
Reserve # in User Name feature allows the phones to reserve “#” in user name. When Reserve # in User Name fea-
ture is disabled, “#” will be converted into “%23”. For example, the user registers an account (user name: 1010#) on
the phone, the phone will send 1010%23 instead of 1010# in the REGISTER message or INVITE message to the
SIP server.
Example of a SIP REGISTER message:
INVITE sip:2@10.2.1.48:5060 SIP/2.0
Via: SIP/2.0/UDP 10.3.20.6:5060;branch=z9hG4bK1867789050
From: "1010" <sip:1010%23@10.2.1.48:5060>;tag=1945988802
To: <sip:2@10.2.1.48:5060>
Call-ID: 0_2336101648@10.3.20.6
CSeq: 1 INVITE
Contact: <sip:1010%23@10.3.20.6:5060>
Content-Type: application/sdp
Allow: INVITE, INFO, PRACK, ACK, BYE, CANCEL, OPTIONS, NOTIFY, REGISTER, SUBSCRIBE, REFER,
PUBLISH, UPDATE, MESSAGE
Max-Forwards: 70
User-Agent: Yealink SIP-T46G 28.82.0.20
Allow-Events: talk,hold,conference,refer,check-sync
Content-Length: 300
Topic
Reserve # in User Name Configuration
Reserve # in User Name Configuration
The following table lists the parameter you can use to configure the reserve # in user name.
Parameter
sip.use_23_as_pound <y0000000000xx>.cfg
Description
It enables or disables the phone to reserve the pound sign (#) in the user name.
Permitted
Values
0-Disabled (convert the pound sign into “%23”)
1-Enabled

Yealink SIP-T53W Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP mobile phone
Product color	Gray
Keypad illumination	Yes
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Security algorithms	AES, HTTPS, SIPS
Networking standards	IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Lines quantity	8 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.3 W
Volume control	Buttons
Number of programmable keys	8
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Number of DECT wireless handsets	4
Voice codecs	G.722, G.723.1, G.726, G.729A, G.729B, OPUS, iLBC

Weight and Dimensions

Depth	210.6 mm
Width	212 mm
Height	174.5 mm
