Yealink SIP-T53W Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
539
The boot log file reports the logs with all severity levels.
The following figure shows a portion of a sys log file (for example, 00156574b150.log):
The <MAC>.log file reports the logs with a configured severity level and the higher. For example, if you have con-
figured the severity level of the log to be reported to the <MAC>.log file to 4, then the log with a severity level of 0 to
4 will all be reported.
Syslog Logging
You can also configure the IP phone to send syslog messages to a syslog server in real time.
You can specify syslog details such as IP address or hostname, server type, facility, and the severity level of events
you want to log. You can also choose to prepend the phone's MAC address to log messages.
Topics
Syslog Logging Configuration
Viewing the Syslog Messages on Your Syslog Server
Syslog Logging Configuration
The following table lists the parameters you can use to configure syslog logging.
Parameter
static.syslog.enable <y0000000000xx>.cfg
Description
It enables or disables the phone to upload log messages to the syslog server in real time.
Permitted
Values
0-Disabled
1-Enabled
Default
0
Web UI
Settings > Configuration > Syslog > Enable Syslog
Parameter
static.syslog.server <y0000000000xx>.cfg

Yealink SIP-T53W Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP mobile phone
Product color	Gray
Keypad illumination	Yes
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Security algorithms	AES, HTTPS, SIPS
Networking standards	IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Lines quantity	8 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.3 W
Volume control	Buttons
Number of programmable keys	8
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Number of DECT wireless handsets	4
Voice codecs	G.722, G.723.1, G.726, G.729A, G.729B, OPUS, iLBC

Weight and Dimensions

Depth	210.6 mm
Width	212 mm
Height	174.5 mm
