Yealink SIP-T53W Administrator's Guide

Phone Provisioning
78
Provisioning Methods Priority
There is a priority for configuration among the provisioning methods - settings you make using a higher priority pro-
visioning method override settings made using a lower priority provisioning method.
The precedence order for configuration parameter changes is as follows (highest to lowest):
Note: The provisioning priority mechanism takes effect only if “static.auto_provision.custom.protect” is set to 1. For more
information on this parameter, refer to Keeping User’s Personalized Settings Configuration.
Static parameters have no priority. They take effect no matter what method (web user interface or phone user inter-
face or configuration files) you are using for provisioning.
Static parameters are the parameters that start with a prefix “static.”, for example, the parameters associated with
auto provisioning/network/syslog, TR069 settings and internal settings (the temporary configurations to be used for
program running).
Web User Interface
You can configure the phones via the web user interface, a web-based interface that is especially useful for remote
configuration.
Because features and configurations vary by phone models and firmware versions, options available on each page
of the web user interface can vary as well. Note that the features configured via the web user interface are limited.
Therefore, you can use the web user interface in conjunction with a central provisioning method and phone user
interface.
When configuring the phones via the web user interface, you require a user name and password for access. For a
user, the default user name and password are “user” (case-sensitive). For an administrator, the default user name
and password are “admin” (case-sensitive).
Note: When you manually configure a phone via the web user interface or phone user interface, the changes associated with
non-static parameters you make will be stored in the MAC-local CFG file. For more information on the MAC-local CFG file,
refer to MAC-local CFG File.
Topics
Accessing the Web User Interface
Quick Login Configuration
Web Server Type Configuration
Navigating the Web User Interface
Accessing the Web User Interface
Procedure
1. Find the device IP address. Press the OK key when the phone is idle or navigate to Menu > Status on the
phone.
2.
Enter the IP address in the address bar of a web browser on your PC.

Yealink SIP-T53W Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP mobile phone
Product color	Gray
Keypad illumination	Yes
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Security algorithms	AES, HTTPS, SIPS
Networking standards	IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Lines quantity	8 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.3 W
Volume control	Buttons
Number of programmable keys	8
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Number of DECT wireless handsets	4
Voice codecs	G.722, G.723.1, G.726, G.729A, G.729B, OPUS, iLBC

Weight and Dimensions

Depth	210.6 mm
Width	212 mm
Height	174.5 mm
