Yealink SIP-T53W Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
549
Devices
Parameter
static.features.network_unavailable_test.period <y0000000000xx>.cfg
Description
It specifies a period of time (in seconds) to detect the network status when the network is unreachable.
Note: It works only if "static.features.network_test.enable" is set to 1 (Enabled).
Permitted
Values
Integer from 2 to 3600
Default
30
Supported
Devices
All phones except T48G, T46G, T42G, T41P and T29G
Analyzing Configuration Files
Wrong configurations may have an impact on phone use. You can export configuration file(s) to check the current
configuration of the IP phone and troubleshoot if necessary. You can also import configuration files for a quick and
easy configuration.
We recommend that you edit the exported CFG file instead of the BIN file to change the phone’s current settings.
The config.bin file is an encrypted file. For more information on config.bin file, contact your Yealink reseller.
Topics
Exporting CFG Configuration Files from Phone
Importing CFG Configuration Files to Phone
Exporting BIN Files from the Phone
Importing BIN Files from the Phone
Exporting CFG Configuration Files from Phone
You can export the phone’s configuration file to local and make changes to the phone’s current feature settings.
You can apply these changes to any phone by importing the configuration files via the web user interface.
You can export five types of CFG configuration files to the local system:
l
<MAC>-local.cfg: It contains changes associated with non-static parameters made via the phone user interface
and web user interface. It can be exported only if “static.auto_provision.custom.protect” is set to 1 (Enabled).
l
<MAC>-all.cfg: It contains all changes made via the phone user interface, web user interface and using con-
figuration files.
l
<MAC>-static.cfg: It contains all changes associated with static parameters (for example, network settings)
made via the phone user interface, web user interface and using configuration files.
l
<MAC>-non-static.cfg: It contains all changes associated with non-static parameters made via the phone user
interface, web user interface and using configuration files.
l
<MAC>-config.cfg: It contains changes associated with non-static parameters made using configuration files. It
can be exported only if “static.auto_provision.custom.protect” is set to 1 (Enabled).
Procedure
1. Navigate to Settings > Configuration > CFG Configuration.
2. In the Export CFG Configuration File block, click Export to open the file download window, and then save the
file to your local system.

Yealink SIP-T53W Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP mobile phone
Product color	Gray
Keypad illumination	Yes
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Security algorithms	AES, HTTPS, SIPS
Networking standards	IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Lines quantity	8 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.3 W
Volume control	Buttons
Number of programmable keys	8
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Number of DECT wireless handsets	4
Voice codecs	G.722, G.723.1, G.726, G.729A, G.729B, OPUS, iLBC

Weight and Dimensions

Depth	210.6 mm
Width	212 mm
Height	174.5 mm
