Yealink SIP-T53W Administrator's Guide

Administrator’s Guide for SIP-T2 Series/T4 Series/T5 Series/CP920 IP Phones
415
Multicast Paging Group Configuration
Yealink phones support up to 31 groups for paging. You can assign multicast IP address with a channel for each
group, and specify a label to each group to identify the phones in the group, such as All, Sales, or HR.
Tip: You can set a DSS key as Multicast Paging key or Paging list key on the phone, which allows you to send announce-
ments to the phones with the pre-configured multicast address(es) on the specific channel(s). For more information, refer to
DSS Keys.
The following table lists the parameters you can use to configure a multicast paging group.
Parameter
multicast.paging_address.X.ip_address
[1]
<y0000000000xx>.cfg
Description
It configures the IP address and port number of the multicast paging group in the paging list.
Permitted
Values
IP address: port (224.0.0.1-239.255.255.255 port: 0-65535)
Default
Blank
Web UI
Directory > Multicast IP > Paging List > Paging Address
Phone UI
Color Screen Phones:
Menu > Features > Others > Paging List > Option > Edit > Address
Black-and-white Screen Phones:
Menu > Features > Paging List > Option > Edit > Address
Parameter
multicast.paging_address.X.label
[1]
<y0000000000xx>.cfg
Description
It configures the name of the multicast paging group to be displayed in the paging list.
It will be displayed on the phone screen when placing the multicast paging calls.
Permitted
Values
String
Default
Blank
Web UI
Directory > Multicast IP > Paging List > Label
Phone UI
Color Screen Phones:
Menu > Features > Others > Paging List > Option > Edit > Label
Black-and-white Screen Phones:
Menu > Features > Paging List > Option > Edit > Label
Parameter
multicast.paging_address.X.channel
[1]
<y0000000000xx>.cfg
Description
It configures the channel of the multicast paging group in the paging list.
Permitted
Values
0-all the Yealink phones running old firmware version or Yealink phones listen to channel 0 or third-
party available devices in the paging group can receive the RTP stream.
1 to 25-the Polycom or Yealink phones preconfigured to listen to the channel can receive the RTP
stream.
26 to 30-the Yealink phones preconfigured to listen to the channel can receive the RTP stream.
Default
0
Web UI
Directory > Multicast IP > Paging List > Paging Address > Channel
Phone UI
Color Screen Phones:
Menu > Features > Others > Paging List > Option > Edit > Channel

Yealink SIP-T53W Specifications

General

Mounting	Desk/Wall
Handset type	Wired handset
Product type	IP mobile phone
Product color	Gray
Keypad illumination	Yes
Wi-Fi standards	802.11a, 802.11g, Wi-Fi 4 (802.11n)
Bluetooth version	4.2
Security algorithms	AES, HTTPS, SIPS
Networking standards	IEEE 802.1p, IEEE 802.1x, IEEE 802.3af
Ethernet LAN interface type	Gigabit Ethernet
Supported network protocols	FTP/TFTP/HTTP/HTTPS
Dual-Tone Multi-Frequency (DTMF) modes	In-band, Out-of band, SIP info
USB 2.0 ports quantity	1
Ethernet LAN (RJ-45) ports	2
Lines quantity	8 lines
Phonebook capacity	1000 entries
Number of VoIP accounts	12
AC adapter input voltage	100 - 240 V
AC adapter output current	1.2 A
AC adapter output voltage	5 V
Power consumption (typical)	2.3 W
Volume control	Buttons
Number of programmable keys	8
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 95 %
Display diagonal	3.7 \
Display resolution	360 x 160 pixels
Cables included	LAN (RJ-45)
Number of handles included	1 pc(s)
Number of DECT wireless handsets	4
Voice codecs	G.722, G.723.1, G.726, G.729A, G.729B, OPUS, iLBC

Weight and Dimensions

Depth	210.6 mm
Width	212 mm
Height	174.5 mm
