YOKOGAWA WT5000 Features Guide

10-4
IM WT5000-01EN
Display Items (Items, Numeric)
The display item options vary depending on the current display.
• All display (All Items)
• 4-, 8-, and 16-value displays (4 Items/8 Items/16Items)
• Matrix display (Matrix)
• Harmonics list single/dual (Hrm List Single/Dual)
For a list of the measurement functions and their descriptions, see “Items That This Instrument Can Measure.”
Click here.
Example of How Measurement Functions Are Displayed in the Numeric Data Display
True rms voltage of element 1
Urms1
Element 1
True rms value
Voltage
Simple average of the currents of the elements in wiring unit ΣA
IdcΣA
Σ function of wiring unit ΣA
Simple average
Current
Voltage of the 20
th
order of element 2
U2(20)
Harmonic order 20
Element 2
Voltage
Simple average of the fundamental currents of the elements in wiring unit ΣB
IΣB(1)
Order 1 (fundamental wave)
Σ function of wiring unit ΣB
Current
10 Numeric Data Display
