10-6
IM WT5000-01EN
All display (All Items)
You cannot change individual measurement functions. Change the display by scrolling the page.
The number of displayed pages is 12.
Harmonic Order (Order (k))
On the All display, this setting is valid on pages 9 and 10. On pages 9 and 10, the order setting appears in the
upper left of the screen.
When you select a function that has harmonic data, you can set the displayed harmonic order within the
following range.
Total (Total value) or 0 (dc) to 500
The harmonic orders that can be specified vary depending on the measurement function. For details, see
“Harmonic Measurement Function Orders.”
The numeric data corresponding to harmonic orders above the maximum measurable harmonic order is
displayed as “-------” (no data). For information about the maximum measurable harmonic order, see “Maximum
Harmonic Order to Be Measured (Max Order).”
Turning the Display of the Numeric Data for All Elements and Wiring Units On and Off
(Display All Elements)
• OFF
The numeric data is displayed in seven columns. When the total number of elements and wiring units is 8 or
more, you can them by using the
and buttons on the Display menu to scroll the screen horizontally.
• ON
When the total number of elements and wiring units is 8 or more, all the numeric data for the elements and
wiring units is displayed in 10 columns using small fonts. If you select ON when the total number of elements
and wiring units is seven or less, the display is the same as when OFF is selected.
10 Numeric Data Display
To Next Page
