YOKOGAWA WT5000 Features Guide

15-3
IM WT5000-01EN
Measured Items
In the Waveform Display
Y+ The vertical-axis (Y-axis) value of cursor 1 (+)
Yx The vertical-axis (Y-axis) value of cursor 2 (x)
ΔY The difference between the vertical-axis (Y-axis) values of cursor 1 (+) and
cursor 2 (x)
X+ The horizontal-axis (X-axis) value of cursor 1 (+)
Xx The horizontal-axis (X-axis) value of cursor 2 (x)
ΔX The difference between the horizontal-axis (X-axis) values of cursor 1 (+)
and cursor 2 (x)
1/ΔX The reciprocal of the difference between the horizontal-axis (X-axis) values
of cursor 1 (+) and cursor 2 (x)
In the Trend Display
Y+ The vertical-axis (Y-axis) value of cursor 1 (+)
Yx The vertical-axis (Y-axis) value of cursor 2 (x)
ΔY The difference between the vertical-axis (Y-axis) values of cursor 1 (+) and
cursor 2 (x)
X+ The horizontal-axis (X-axis) value of cursor 1 (+)
With the left edge of the screen being 0 seconds, the time from the left
edge of the screen is indicated.
Xx The horizontal-axis (X-axis) value of cursor 2 (x)
With the left edge of the screen being 0 seconds, the time from the left
edge of the screen is indicated.
ΔX The difference between the horizontal-axis (X-axis) values of cursor 1 (+)
and cursor 2 (x)
D+ The date and time at the position of cursor 1 (+)
The date and time of measurement are displayed in this format: Year/
Month/Day Hour:Minute:Second.
Dx The date and time at the position of cursor 2 (x)
The date and time of measurement are displayed in this format: Year/
Month/Day Hour:Minute:Second.
• If immeasurable data exists, “***” is displayed in the measured value display area.
• ΔY can be measured even when the units of the cursors are different. The measured result will not have a
unit.
In the Bar Graph Display
Y1+ The vertical-axis (Y-axis) value of cursor 1 (+) of bar graph 1
Y1x The vertical-axis (Y-axis) value of cursor 2 (x) of bar graph 1
ΔY1 The difference between the vertical-axis (Y-axis) values of cursor 1 (+) and
cursor 2 (x) of bar graph 1
Y2+ The vertical-axis (Y-axis) value of cursor 1 (+) of bar graph 2
Y2x The vertical-axis (Y-axis) value of cursor 2 (x) of bar graph 2
ΔY2 The difference between the vertical-axis (Y-axis) values of cursor 1 (+) and
cursor 2 (x) of bar graph 2
Y3+ The vertical-axis (Y-axis) value of cursor 1 (+) of bar graph 3
Y3x The vertical-axis (Y-axis) value of cursor 2 (x) of bar graph 3
ΔY3 The difference between the vertical-axis (Y-axis) values of cursor 1 (+) and
cursor 2 (x) of bar graph 3
15 Cursor Measurement
