10-7

IM WT5000-01EN

4-, 8-, and 16-Value Displays (4 Items/8 Items/16 Items)

Item Number to Set (Item No.)

Select the number of the item that you want to configure.

Function (Function)

You can select any of the measurement function types listed under “Items That This Instrument Can Measure.”

Click here.

If you select None, no measurement function is displayed for the selected item.

Element (Element/Σ)

• When the function (Function) is set to something other than Speed, Torque, Pm, Slip, or SyncSp

• Depending on the function, select the element/wiring unit from the following options, or you may not need

to select it. The available options vary depending on the installed elements.

Element1, Element2, Element3, Element4, Element5, Element6, Element7, ΣA, ΣB, ΣC

• If the selected wiring unit does not have any elements assigned to it, because there is no data, “-------” (no

data) is displayed. For example, if elements are assigned to ΣA but not to ΣB, the measurement function

for ΣB is displayed as “-------” (no data).

• If you select Speed, Torque, Pm, Slip, or SyncSp for the function (Function), select the motor number from the

following options. The options vary depending on the installed motor evaluation function option.

Motor 1, Motor 2, Motor 3, Motor 4

Harmonic Order (Order (k))

This is the same feature as the harmonic orders on the All display.

Click here.

Resetting the Display Items (Reset Items)

Reset Patterns (Reset Pattern)

You can select the reset method from the following options.

• Element Origin (Element Origin)

The numeric data for each element is displayed on each page. The pattern that the data is arranged in varies

depending on the number of installed elements.

• Function Origin (Function Origin)

The numeric data for each function is displayed on each page. The pattern that the data is arranged in varies

depending on the number of installed elements.

• Clear Current Page (Clear Current Page)

All the display items on the current page are set to None.

• Clear All Pages (Clear All Pages)

All the display items on every page are set to None.

Resetting the Items (Reset Items Exec)

Reset the items.

10 Numeric Data Display
