Symbologies 12 - 37

Transmit Code 11 Check Digits

This feature selects whether or not to transmit the Code 11 check digit(s).

Transmit Code 11 Check Digit(s)

(Enable)

*Do Not Transmit Code 11 Check Digit(s)

(Disable)

NOTE You must enable Code 11 Check Digit Verification for this parameter to function.
