6 - 4 LS2208 Product Reference Guide
RS-232 Host Parameters
The RS-232 hosts listed in Table 6-2 use their own parameter default settings. Selecting the ICL, Fujitsu,
Wincor-Nixdorf Mode A, Wincor-Nixdorf Mode B, Olivetti, Omron, or terminal sets the defaults listed.
Table 6-2 Terminal Specific RS-232
Parameter
Standard
(Default)
ICL Fujitsu
Wincor-
Nixdorf
Mode A
Wincor-
Nixdorf
Mode B/
OPOS
Olivetti Omron
Transmit Code ID No Yes Yes Yes Yes Yes Yes
Data Transmission
Format
Data as is Data/
Suffix
Data/
Suffix
Data/Suffix Data/Suffix Prefix/Data/
Suffix
Data/
Suffix
Suffix CR/LF
(7013)
CR
(1013)
CR
(1013)
CR (1013) CR (1013) ETX (1002) CR
(1013)
Baud Rate 9600 9600 9600 9600 9600 9600 9600
Parity None Even None Odd Odd Even None
Hardware
Handshaking
None RTS/CTS
Option 3
None RTS/CTS
Option 3
RTS/CTS
Option 3
None None
Software
Handshaking
None None None None None Ack/Nak None
Serial Response
Time-out
2 Sec. 9.9 Sec. 2 Sec. 9.9 Sec. 9.9 Sec. 9.9 Sec. 9.9 Sec.
Stop Bit Select One One One One One One One
ASCII Format 8-Bit 8-Bit 8-Bit 8-Bit 8-Bit 7-Bit 8-Bit
Beep On <BEL> Disable Disable Disable Disable Disable Disable Disable
RTS Line State Low High Low Low Low = No
data to send
Low High
Prefix None None None None None STX (1003) None
*In the Nixdorf Mode B, if CTS is low, scanning is disabled. When CTS is high, scanning is enabled.
**If you scan Nixdorf Mode B without connecting the scanner to the proper host, it may appear unable
to scan. If this occurs, scan a different RS-232 host type within 5 seconds of cycling power to the
scanner.
