Zetor MAJOR User Manual

Selection of road or reduced speeds
Gear shifting
Selecting driving direction - Reversing lever
Road and reduced gears lever serves for shifting groups
of gears.
Gear shifting to be done with tractor at
standstill and depressed clutch pedal.
H Road speeds
M Average speeds
N Neutral
L Reduced speeds
NM13N046
Gear shifting lever serves for changes of gear box gears.
Gear shifting is done with a depressed clutch pedal.
Only gears are shifted by main gear shifting
lever, the direction of travel is shifted by reversing
lever.
NM13N045
Reversing lever (1) serves for the change of tractor's
travel direction.
F - drive forward, lever in the front
N - neutral
R - reversing; lever at the back
Gear shifting is done with tractor at standstill and clutch
pedal depressed.
NM13N044
DRIVING OPERATION
40

Zetor MAJOR Specifications

General

Hydraulic System	Open center
Displacement	4.156 l
Number of Cylinders	4
PTO Speed	540/1000 rpm
Engine Type	Zetor
Engine	Zetor
