Operation Manual / A200-L
9 Disassembly and assembly / 9.1 Introduction
© Copyright 2021 ABB. All rights reserved. HZTL4036_EN Rev.T December 2021
9 Disassembly and assembly
9.1 Introduction
CAUTION
Further work
This Operation Manual may be used to carry out only the work described in
it. Further work that is carried out in an incorrect way can lead to serious
damage to the machine.
u ABB Turbocharging recommends having further work carried out only by
trained personnel from an ABB Turbocharging Service Station.
u Mark the casing position for assembly.
Tightening torques for components
The specified tightening torques of the bolted connections must be observed.
Tightening torques for assembly devices
Unless otherwise described, the screws and nuts of the assembly devices supplied by ABB
must be tightened in such a way that they are tight-fitting.
WARNING
Suspended loads
Loads that are not attached according to regulations can cause injury to
personnel or fatal accidents.
u Only fasten the turbocharger, assemblies or individual parts on properly
functional lifting gear with sufficient load limit.
u Pay attention to the correct attachment of loads on the crane hook.
u People must not stand beneath suspended loads.
Wear safety gloves to protect against mechanical hazards.
Wear safety helmet.
