ABB ACS850 User Manual

Parameters 105
02.03 DIO status Status of digital input/outputs DIO10…DIO1. Example:
0000001001 = DIO1 and DIO4 are on, remainder are off.
DIO3…DIO10 are available only with FIO I/O extension
modules.
-
02.04 AI1 Value of analogue input AI1 in V or mA. Input type is selected
with jumper J1 on the JCU Control Unit.
1000 = 1 unit
02.05 AI1 scaled Scaled value of analogue input AI1. See parameters 13.04
AI1 max scale and 13.05 AI1 min scale.
1000 = 1 unit
02.06 AI2 Value of analogue input AI2 in V or mA. Input type is selected
with jumper J2 on the JCU Control Unit.
1000 = 1 unit
02.07 AI2 scaled Scaled value of analogue input AI2. See parameters 13.09
AI2 max scale and 13.10 AI2 min scale.
1000 = 1 unit
02.08 AI3 Value of analogue input AI3 in V or mA. For input type
information, see the extension module manual.
1000 = 1 unit
02.09 AI3 scaled Scaled value of analogue input AI3. See parameters 13.14
AI3 max scale and 13.15 AI3 min scale.
1000 = 1 unit
02.10 AI4 Value of analogue input AI4 in V or mA. For input type
information, see the extension module manual.
1000 = 1 unit
02.11 AI4 scaled Scaled value of analogue input AI4. See parameters 13.19
AI4 max scale and 13.20 AI4 min scale.
1000 = 1 unit
02.12 AI5 Value of analogue input AI5 in V or mA. For input type
information, see the extension module manual.
1000 = 1 unit
02.13 AI5 scaled Scaled value of analogue input AI5. See parameters 13.24
AI5 max scale and 13.25 AI5 min scale.
1000 = 1 unit
02.14 AI6 Value of analogue input AI6 in V or mA. For input type
information, see the extension module manual.
1000 = 1 unit
02.15 AI6 scaled Scaled value of analogue input AI6. See parameters 13.29
AI6 max scale and 13.30 AI6 min scale.
1000 = 1 unit
02.16 AO1 Value of analogue output AO1 in mA. 1000 = 1 mA
02.17 AO2 Value of analogue output AO2 in mA. 1000 = 1 mA
02.18 AO3 Value of analogue output AO3 in mA. 1000 = 1 mA
02.19 AO4 Value of analogue output AO4 in mA. 1000 = 1 mA
02.20 Freq in Scaled value of DIO1 when it is used as a frequency input.
See parameters 14.02 DIO1 conf and 14.57 Freq in max.
1000 = 1
02.21 Freq out Frequency output value of DIO2 when it is used as a
frequency output (parameter 14.06 is set to Freq output).
1000 = 1 Hz
No. Name/Value Description FbEq
