ABB ACS850 User Manual

Parameters 173
21.10 Mot pot func Selects whether the value of the motor potentiometer is
retained upon drive power-off.
Reset Drive power-off resets the value of the motor potentiometer. 0
Store The value of the motor potentiometer is retained over drive
power-off.
1
21.11 Mot pot up Selects the source of motor potentiometer up signal.
DI4 Digital input DI4 (as indicated by 02.01 DI status, bit 3). 1073938945
DI5 Digital input DI5 (as indicated by 02.01 DI status, bit 4). 1074004481
DI6 Digital input DI6 (as indicated by 02.01 DI status, bit 5). 1074070017
Const Bit pointer setting (see Terms and abbreviations on page
102).
-
Pointer
21.12 Mot pot down Selects the source of motor potentiometer down signal.
DI4 Digital input DI4 (as indicated by 02.01 DI status, bit 3). 1073938945
DI5 Digital input DI5 (as indicated by 02.01 DI status, bit 4). 1074004481
DI6 Digital input DI6 (as indicated by 02.01 DI status, bit 5). 1074070017
Const Bit pointer setting (see Terms and abbreviations on page
102).
-
Pointer
22
22 Speed ref ramp
Speed reference ramp settings.
22.01 Acc/Dec sel Selects the source that switches between the two sets of
acceleration/deceleration times defined by parameters
22.02…22.05.
0 = Acceleration time 1 and deceleration time 1 are in force
1 = Acceleration time 2 and deceleration time 2 are in force.
DI1 Digital input DI1 (as indicated by 02.01 DI status, bit 0). 1073742337
DI2 Digital input DI2 (as indicated by 02.01 DI status, bit 1). 1073807873
DI3 Digital input DI3 (as indicated by 02.01 DI status, bit 2). 1073873409
DI4 Digital input DI4 (as indicated by 02.01 DI status, bit 3). 1073938945
DI5 Digital input DI5 (as indicated by 02.01 DI status, bit 4). 1074004481
DI6 Digital input DI6 (as indicated by 02.01 DI status, bit 5). 1074070017
Const Bit pointer setting (see Terms and abbreviations on page
102).
-
Pointer
22.02 Acc time1 Defines acceleration time 1 as the time required for the speed
to change from zero to the speed value defined by parameter
19.01 Speed scaling.
If the speed reference increases faster than the set
acceleration rate, the motor speed will follow the acceleration
rate.
If the speed reference increases slower than the set
acceleration rate, the motor speed will follow the reference
signal.
If the acceleration time is set too short, the drive will
automatically prolong the acceleration in order not to exceed
the drive torque limits.
0.000 … 1800.000
s
Acceleration time 1. 1000 = 1 s
