142 Parameters
Spd ref Safe The drive generates an AI SUPERVISION alarm and sets the
speed to the speed defined by parameter 30.02 Speed ref
safe.
WARNING! Make sure that it is safe to continue
operation in case of a communication break.
2
Last speed The drive generates an AI SUPERVISION alarm and freezes
the speed to the level the drive was operating at. The speed
is determined by the average speed over the previous 10
seconds.
WARNING! Make sure that it is safe to continue
operation in case of a communication break.
3
13.33 AI superv cw Selects the analogue input signal supervision limit.
Example: If parameter value is set to 0b0010, bit 1 AI1>max
is selected.
14
14 Digital I/O
Configuration of digital input/outputs and relay outputs.
14.01 DI invert mask Inverts status of digital inputs as reported by 02.01 DI status.
14.02 DIO1 conf Selects whether DIO1 is used as a digital output, digital input
or frequency input.
Output DIO1 is used as a digital output. 0
Input DIO1 is used as a digital input. 1
Freq input DIO1 is used as a frequency input. 2
14.03 DIO1 out src Selects a drive signal to be connected to digital output DIO1
(when 14.02 DIO1 conf is set to Output).
Brake cmd 03.16 Brake command (see page 115). 1073742608
Ready Bit 0 of 06.01 Status word1 (see page 116). 1073743361
No. Name/Value Description FbEq
Bit Supervision Action selected by parameter 13.32 AI superv func is taken if
0 AI1 min sup AI1 signal value falls below the value defined by equation: par. 13.03
AI1 min - 0.5 mA or V
1 AI1 max sup AI1 signal value exceeds the value defined by equation: par. 13.02
AI1 max + 0.5 mA or V
2 AI2 min sup AI2 signal value falls below the value defined by equation: par. 13.08
AI2 min - 0.5 mA or V
3 AI2 max sup AI2 signal value exceeds the value defined by equation: par. 13.07
AI2 max + 0.5 mA or V
Bit Name
0 1 = Invert DI1
1 1 = Invert DI2
2 1 = Invert DI3
3 1 = Invert DI4
4 1 = Invert DI5
5 1 = Invert DI6
6 Reserved
7 1 = Invert DI8 (on optional FIO-21 I/O Extension)
