86 Program features
Amplitude logger 1 is fixed to monitor motor current, and cannot be reset. With
amplitude logger 1, 100% corresponds to the maximum output current of the drive
(I
Max
).
Settings
Parameter group 64 Load analyzer (page 244).
Miscellaneous
îš„ Backup and restore of drive contents
General
The drive offers a possibility of backing up numerous settings and configurations to
external storage such as a PC file (using the DriveStudio tool) and the internal
memory of the control panel. These settings and configurations can then be restored
to the drive, or a number of drives.
Backup using DriveStudio includes
• Parameter settings
• User parameter sets
• Application program.
Percentage of samples
0…10%
10…20%
20…30%
30…40%
40…50%
50…60%
60…70%
70…80%
80…90%
>90%
Amplitude ranges
(parameters 64.24…64.33)
