ABB ACS850 User Manual

110 Parameters
02.31 D2D follower cw Drive-to-drive control word sent to the followers by default.
See also parameter group 57 D2D communication on page
239.
-
02.32 D2D ref1 Drive-to-drive reference 1 received from the master. 1 = 1
02.33 D2D ref2 Drive-to-drive reference 2 received from the master. 1 = 1
02.34 Panel ref Reference given from the control panel. See also parameter
56.07 Local ref unit.
100 = 1 rpm
10 = 1%
02.35 FEN DI status Status of the digital inputs of FEN-xx encoder interfaces in
drive option slots 1 and 2. Examples:
000001 (01h) = DI1 of FEN-xx in slot 1 is ON, all others are
OFF.
000010 (02h) = DI2 of FEN-xx in slot 1 is ON, all others are
OFF.
010000 (10h) = DI1 of FEN-xx in slot 2 is ON, all others are
OFF.
100000 (20h) = DI2 of FEN-xx in slot 2 is on, all others are
OFF.
-
No. Name/Value Description FbEq
Bit Information
0 Stop.
1Start.
2 … 6 Reserved.
7 Run enable.
8Reset.
9 … 14 Freely assignable through bit pointer settings.
15 EXT1/EXT2 selection. 0 = EXT1 active, 1 = EXT2 active.

ABB ACS850 Specifications

General

Safety	STO (Safe Torque Off)
Communication	CANopen
Enclosure	IP21
Output Voltage	Up to 1000 V DC
Protection Features	Overcurrent, Overvoltage, Undervoltage
Cooling Method	Air or liquid cooling
Input Voltage	380 to 690 V AC
