Chapter 1 - Introduction
IV F
1 - 2 DCS 600 Operating Instructions
Incoming inspection
After opening this package, you should check whether it contains
the following items:
● DCS 600 thyristor power converter in the configuration
ordered
● DCS 600 publications
● Accessories, including manuals if ordered
● Final test report
Check the consignment for any signs of damage. If you find any,
please contact the insurance company or the supplier.
Check the particulars given on the unit’s rating plate to make sure
prior to installation and start-up that you have received the correct
unit type and unit version.
If the consignment is incomplete or contains any incorrect items,
please contact the supplier.
CAUTION! The thyristor power converter weighs quite a lot and
should therefore not be held by the front cover. Please put the unit
down only on its back (sizes C1 to C3). Always use due care when
handling the unit, so as to avoid injuries or damage.
Storage and transport
If the unit had been in storage prior to installation or is transported
to another location, care must be taken to ensure that the environ-
mental conditions are complied with (see "System Description
DCS 600").
Rating plate
For purposes of identification, each thyristor power converter is fit-
ted with rating plates, stating the type code and the serial number,
which serve for each unit’s individual identification.
The type code contains information on the characteristics and the
configuration of the unit. The first three digits of the serial number
refer to the year and week of manufacture. The last digits complete
the serial number so as to preclude two units receiving the same
type code and the same serial number.
The group 4 provides information on the unit’s software configura-
tion.
The technical data and specifications are valid as of going to press.
ABB reserves the right to make subsequent alterations.
If you have any questions concerning your drive system, please
contact your local ABB agent.
