Chapter 2 - Start-Up Instructions
IV F
2 - 24 DCS 600 Operating Instructions
2.10 Start-Up of the serial communication
DCS 600 and APC
Hardware
DCS 600 SDCS-AMC-DC board
APC YPQ112B board
Cable length 0.2 ... 20 m plastic optical fibre
Configuration YPQ112 first board channel 1 Drive No 1
...
channel 4 Drive No 4
second board channel 1 Drive No 5
...
channel 4 Drive No 8
Associated publications
DCS 600 Technical Data 3ADW000054R0301 ABB Lampertheim
Software Description 3ADW000076R0401 ABB Lampertheim
Database GLOBAL\DEIND\DEIND051.NSF
APC FCB function block 3AFY61281240 ABB Helsinki
YPQ 112 3AFY63982806 ABB Helsinki
Database GLOBAL\FIDRI\FIDRI002.NSF
Software settings
DCS 600 Parameter 98.02 = 3 (ADVANT)
70.01 = 1 (fixed)
99.10 = Drive No (see above)
70.02 = Optical power/ cable length
(use default)
70.20 = 10
71.21 = Star
Default connected Main control word (data set 10/1)
parameters Speed reference (data set 10/2)
Main status word (data set 11/1)
Motor speed (data set 11/2)
For additional p. see SW Descr. chap. ”Communication”
APC Node Type APC2.2/1 Station 0,0
DB element ACS01, ACS02, ACS03
Type YPQ112A up to four drives
YPQ112B more than four drives
Drtype = ACS600 MultiDrive (high performance)
ACS600 SingleDrive (low performance)
FB ACSRX1
Control word 7.01 = bit10 = 1
(send to drive)
Example for switch-on sequence
Send to control word 7.01 0476H (ON = 0; READY, if there is no failure)
0477H (main contactor ON)
047FH (RELEASE for speed and current control)
Note: Before receiving the first dataset the drive sets the CH 0 alarm status
