ABB DCS 600 MultiDrive User Manual

Chapter 2 - Start-Up Instructions
DCS 600 Operating Instructions IV F 2 - 31
DCS 600 and Modbus PLUS
Hardware
DCS 600 SDCS-AMC-DC classic board
NMBP-01 Software 1.3
Cable length 0.2 ... 10 m plastic optical fibre
Associated publications
DCS 600 Technical Data 3ADW000054R0301 ABB Lampertheim
Software Description 3ADW000076R0401 ABB Lampertheim
DC Converter Fieldbus 3ADW000097R0101 ABB Lampertheim
(not on database)
Database GLOBAL\DEIND\DEIND051.NSF
Modbus NMBP-01 3AFY58919802R0125RevB ABB Helsinki
PLUS Database GLOBAL\FIDRI\FIDRI002.NSF
Software settings
DCS 600 Parameter 98.02 = 2 (FIELDBUS)
70.01 = 1
70.02 = Optical power/cable length
(use default)
70.20 = 1
Default connected Main control word (data set 1/1)
parameters Speed reference (data set 1/2)
Main status word (data set 2/1)
Motor speed (data set 2/2)
Drive
Parameter
Fieldbus
Par. No.
Parameter Name Select
51.01 1 MODULE TYPE MODBUS PLUS
51.02 2 MODULE MODE 0
51.03 3 DRIVE NUMBER 2 to 64
51.04 4 GOOD MESSAGES 0 to 32767
51.05 5 BAD MESSAGES 0 to 32767
51.06 6 GLOBAL DATA OUT 1 1
51.07 7 GLOBAL DATA OUT 2 0 to 6
51.08 8 GLOBAL DATA OUT 3 0 to 6
51.09 9 GDATA IN 1STATION 1 to 64 PLC station No.
51.10 10 GDATA IN 1WORD 1
= Self-adjustment while switching on
To be continued!
