Chapter 2 - Start-Up Instructions
DCS 600 Operating Instructions
IV F
2 - 33
DCS 600 and CS 31
Hardware
DCS 600 SDCS-AMC-DC Classic board
NCSA Software V1.5
Cable length 0.2 ... 10 m plastic optical fibre
Associated publications
DCS 600 Technical Data 3ADW000054R0301 ABB Lampertheim
Software Description 3ADW000076R0401 ABB Lampertheim
DC Converter Fieldbus 3ADW000097R0101 ABB Lampertheim
(not on database)
Database GLOBAL\DEIND\DEIND051.NSF
CS 31 NCSA-01 3ADW000043R0201 ABB Lampertheim
Software settings
DCS 600 Parameter 98.02 = 2 (FIELDBUS)
70.01 = 1
70.02 = Optical power/cable length
(use default)
70.20 = 1
Default connected Main control word (data set 1/1)
parameters Speed reference (data set 1/2)
Main status word (data set 2/1)
Motor speed (data set 2/2)
Drive
Parameter
Fieldbus
Par. No.
Parameter Name Select
51.01 1 MODULE TYPE NCSA-01 V1.5
51.02 2 PROTOCOL ABB CS31
51.03 3 MODULU ID 0:WORD
51.04 4 DRIVE NUMBER 0…5 Station No.
51.05 5 ADDR WDEX 0:LOWER
51.06 6 DATA SETS 1…3 sent + receive
51.07 7 DATA SET1 CONST 1 (1 =
^
6ms)
51.08 8 DATA SET2 CONST 1 (1 =
^
6ms)
51.09 9 DATA SET3 CONST 1 (1 =
^
6ms)
51.10 10 DATA SET OFSET 1
= Self-adjustment while switching on
Note: After change of Parameters Group 51 switch OFF and ON the DCS 600 and the
Fieldbus adapter!
Notice: Software bug V1.5: Only one adapter in CS 31 network is too fast for drive communica-
tion!
