ABB DCS 600 MultiDrive User Manual

Chapter 2 - Start-Up Instructions
DCS 600 Operating Instructions IV F 2 - 29
DCS 600 and Profibus
Hardware
DCS 600 SDCS-AMC-DC Classic board
NPBA02 Software V2.2
Cable length 0.2 ... 10 m plastic optical fibre
Associated publications
DCS 600 Technical Data 3ADW000054R0301 ABB Lampertheim
Software Description 3ADW000076R0401 ABB Lampertheim
DC Converter Fieldbus 3ADW000097R0101 ABB Lampertheim
(not on database)
Database GLOBAL\DEIND\DEIND051.NSF
Profibus NPBA 3AFY58995789R0125 ABB Helsinki
Database GLOBAL\FIDRI\FIDRI002.NSF
Software settings
DCS 600 Parameter 98.02 = 2 (FIELDBUS)
70.01 = 1
70.02 = Optical power/cable length
(use default)
70.20 = 1
Default connected Main control word (data set 1/1)
parameters Speed reference (data set 1/2)
Main status word (data set 2/1)
Motor speed (data set 2/2)
Drive
Parameter
Fieldbus
Par. No.
Parameter Name Select
51.01 1 MODULE TYPE PROFIBUS
51.02 2 PROFIBUS MODE DP-PPO1 or DP-PPO2
51.03 3 DRIVE NUMBER 2 to 126
51.04 4 BIT RATE SELECT
PROFIBUS
9.6, 19.2, 93.75, 187.5, 500 KBIT;
1.5 MBIT; AUTO
51.05 5 DATA SET PAIRS
4
{1, 3, 5, 7 sent to drive}
{2, 4, 6, 8 received from drive}
51.06 6 DATA SET OFFSET 0
51.07 7 CUT-OFF TIMEOUT 0 to 255
51.08 8 COM PROFILE 0
Note: After change of Parameters Group 51 switch OFF and ON the DCS 600 and the
Fieldbus adapter!
To be continued!
= Self-adjustment while switching on
