Chapter 2 - Start-Up Instructions
IV F
2 - 26 DCS 600 Operating Instructions
DCS 600 and AC 80 Module bus
Hardware
DCS 600 SDCS-AMC-DC board
AC 80 TB810 board
Cable length 0.2 ... 20 m plastic optical fibre
Transmission speed 4Mb
Ring configuration up to 12 drives
Star configuration (NDBU95) up to 9 drives
Associated publications
DCS 600 Technical Data 3ADW000054R0301 ABB Lampertheim
Software Description 3ADW000076R0401 ABB Lampertheim
Database GLOBAL\DEIND\DEIND051.NSF
AC 80 AC 80 User manual 3BFE 64116487
AC 80 Reference manual 3BFE 64021737
Data base GLOBAL\FIDRI\FIDRI002.NSF
Software settings
DCS 600 Parameter 98.02 = 3 (ADVANT)
70.01 = Drive Number
70.02 = Optical power/cable length
(use default)
70.20 = 10
71.21 = Star or Ring
Connected parameters Main control word (data set 10/1)
Speed reference (data set 10/2)
Main status word (data set 11/1)
Motor speed (data set 11/2)
For additional p. see SW Descr. chap. ”Communication”
AC 80 Node Type AC 80
DB element DRIENG1 Type = Customer string
Ref1 = DRIDS 1
Position = Drive Number
101 ... 112 = 17 ... 28
201 ... 212 = 33 ... 44
... = ...
701 ... 712 = 113 ... 124
DRIDS for sending and receiving one Dataset to/from Drive
WR_ENA = 1 (use ”move element”)
ACT = 1 (use ”move element”)
DS_No = start with ten for the
first dataset to be sent
O-terminals intended for data received
from drive
I-terminals intended for data sent to drive
Control word (send to drive) 7.01 = bit10 = 1
Example for switch-on sequence
Send to control word 7.01 0476H (ON = 0; READY, if there is no failure)
0477H (main contactor ON)
047FH (RELEASE for speed and current control)
Note: Before receiving the first dataset the drive sets the CH 0 alarm status
