Chapter 2 - Start-Up Instructions
DCS 600 Operating Instructions
IV F
2 - 27
DCS 600 and AC 80 Drive bus
Hardware
DCS 600 SDCS-AMC-DC board
AC 80 Drive bus
Cable length 0.2 ... 20 m plastic optical fibre
Transmission speed 4Mb
Star configuration (NDBU95) up to 12 drives - select Drive bus mode
Associated publications
DCS 600 Technical Data 3ADW000054R0301 ABB Lampertheim
Software Description 3ADW000076R0401 ABB Lampertheim
Database GLOBAL\DEIND\DEIND051.NSF
AC 80 AC 80 User manual 3BFE 64116487
AC 80 Reference manual 3BFE 64021737
Data base GLOBAL\FIDRI\FIDRI002.NSF
Software settings
DCS 600 Parameter 98.02 = 3 (ADVANT)
70.01 = Drive Number
70.02 = Optical power/cable length
(use default)
70.20 = 10
71.21 = Star
Connected parameters Main control word (data set 10/1)
Speed reference (data set 10/2)
Main status word (data set 11/1)
Motor speed (data set 11/2)
For additional p. see SW Descr. chap. ”Communication”
AC 80 Node Type AC 80
DB element DRB00 DRTYP1 = AMC Classic for AMC DC
DRTYP1 = NAMC 2 for AMC DC Drive Bus
PC element ACSRX DRNR = Drive number
EN = 1
CNTRL = 1
DS1 = Data set number
WR = 1
Maximum two data sets in one ACSRX block AMC DC
Example for switch-on sequence
Send to control word 7.01 0476H (ON = 0; READY, if there is no failure)
0477H (main contactor ON)
047FH (RELEASE for speed and current control)
Note: Before receiving the first dataset the drive sets the CH 0 alarm status
To Next Page
