Chapter 2 - Start-Up Instructions
IV F
2 - 28 DCS 600 Operating Instructions
DCS 600 and FCI (CI 810) / AC 400
Hardware
DCS 600 SDCS-AMC-DC board
FCI/AC 400 TB810 board Software release 1.3 or later
Cable length 0.2 ... 20 m plastic optical fibre
Transmission speed 4Mb
Ring configuration up to 12 drives
Star configuration (NDBU95) up to 9 drives
Associated publications
DCS 600 Technical Data 3ADW000054R0301 ABB Lampertheim
Software Description 3ADW000076R0401 ABB Lampertheim
Database GLOBAL\DEIND\DEIND051.NSF
FCI Functional unit part 9 DRICONE 3BSE 013947R0001 ABB Sweden
FCB Type circuits Drives Objects 3BSE 013131R0201 ABB Sweden
Drives FCB type circuits 3BSE013855R0001 ABB Sweden
Adva command Drives integration 3BSE012859R0001 ABB Sweden
NOTE: Load the option ”Drive Integration”, if the operation station is installed!
Software settings
DCS 600 Parameter 98.02 = 3 (ADVANT)
70.01 = Drive Number
70.02 = Optical power/cable length
(use default)
70.20 = 10
71.21 = Star or Ring
Connected parameters Main control word (data set 10/1)
Speed reference (data set 10/2)
Main status word (data set 11/1)
Motor speed (data set 11/2)
For additional p. see SW Descr. chap. ”Communication”
FCI Node Type AC 400
DB element DRIENG1 Type = Customer string
Station = Switch at FCI
Postion = Drive Number
FB DRI-S For sending data sets (10,12,14...)
DRI-R For receiving data set (11,13,15...)
[start with ten for the first dataset to be sent]
Control word 7.01 = bit10 = 1
(send to drive)
Example for switch-on sequence
Send to control word 7.01 0476H (ON = 0; READY, if there is no failure)
0477H (main contactor ON)
047FH (RELEASE for speed and current control)
Note: Before receiving the first dataset the drive sets the CH 0 alarm status
