ABB DCS880 H1 User Manual

Accessories
121
3ADW000462R0301 DCS880 Hardware Manual e c
DCF803-0016 and DCF803-0035 configuration (H1 ... H8)
3-phase connection, see also parameters 28.63 and 42.68.
Single-phase connection, see also parameters 28.63 and 42.68.
SF_DCF_003_FEX4_a.ai
DCF803-0016 / 35
F3.1
SDCS-FEX-4
K3 L3
U1
V1
W1
Supply voltage max. 500 V
AC
D1 (-)
5 A (+)
16 / 35 A (+)
SF_DCF_003_FEX4_a.ai
DCF803-0016 / 35
F3.1
SDCS-FEX-4
K3 L3
U1
V1
W1
Max. 500 V
AC
D1 (-)
5 A (+)
16 / 35 A (+)
F3.2 T3
Single phase
Supply voltage
max. 600 V
AC

ABB DCS880 H1 Specifications

General

Rated current	Up to 5200A
Enclosure class	IP00, IP21, IP54
Mounting	Cabinet-mounted
Fieldbus communication	CANopen
Safety	STO (Safe Torque Off)
Output current	Up to 5200A
Communication protocols	PROFIBUS DP, CANopen
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Enclosure rating	IP00, IP21, IP54
Cooling method	Air or liquid cooling
