ABB DCS880 H1 User Manual

The DCS880
13
3ADW000462R0301 DCS880 Hardware Manual e c
The DCS880
Chapter overview
This chapter describes briefly the operating principle and construction of the
converter modules in short.
The DCS880 converter modules
The DCS880-S size H1 ... H8 are intended for controlling DC motors.
Size H1 ... H5
20 ... 1190 A
Size H6
900 ... 2000 A
Size H7
1900 ... 3000 A
Size H8
2050 ... 5200 A

ABB DCS880 H1 Specifications

General

Rated current	Up to 5200A
Enclosure class	IP00, IP21, IP54
Mounting	Cabinet-mounted
Fieldbus communication	CANopen
Safety	STO (Safe Torque Off)
Output current	Up to 5200A
Communication protocols	PROFIBUS DP, CANopen
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Enclosure rating	IP00, IP21, IP54
Cooling method	Air or liquid cooling
