Optical power link board SDCS-OPL-H01 (H7, H8)
Module sizes H7 and H8 consist of a control unit and a power unit. The board provides the interface
between control unit and power unit using fiber optic cables.
Following connectors are available
Fiber optic connectors V1, V2 connect the SDCS-CON-H01 via SDCS-DSL-H1x for control.
Fiber optic connectors V11, V12 connect the SDCS-CON-H01 via SDCD-DSL-H1x for Safe Torque
Off (STO).
Connector X4 is a connection point for a scope to measure the armature current directly over the
burden resistor.
Connector XC12 connects the SDCS-PIN-H51.
Connector XS13 connects the SDCS-PIN-H41.
Connector X38 connects the SDCS-POW-H01.
Connector XSMC (X96) connects the mains connector.
XSMC (X96): Mains contactor
MCCOM Fixed output for the mains contactor
250 V
AC
/ 30 V
DC
, 2 A
Maximum wire size 2.5 mm
2
Varistor protected
MCNO
STOCOM Fixed output for safe torque off (STO) zero current monitor
250 V
AC
/ 30 V
DC
, 2 A
Maximum wire size 2.5 mm
2
Varistor protected
STONO
Mains contactor ON command:
06.24.b07 Current controller status word 1
X4 Current measurement
1 IACT Connection point for a scope
2 - -
3 - -
4 GND1 Common ground (connected to frame)
SA_880_013_OPL_a.ai
XSMC (X96) Mains contactor
1 MCCOM 250 V
AC
/ 30 V
DC
Fixed output for the mains
2 MCNO 2 A contactor
3 STOCOM 250 V
AC
/ 30 V
DC
Fixed output for safe torque
4 STONO 2 A off (STO) zero current monitor
SA_880_013_OPL_a.ai

ABB DCS880 H1 Specifications

General

Rated current	Up to 5200A
Enclosure class	IP00, IP21, IP54
Mounting	Cabinet-mounted
Fieldbus communication	CANopen
Safety	STO (Safe Torque Off)
Output current	Up to 5200A
Communication protocols	PROFIBUS DP, CANopen
Protection features	Overcurrent, overvoltage, undervoltage, overtemperature
Enclosure rating	IP00, IP21, IP54
Cooling method	Air or liquid cooling
