Resetting parameters to factory defaults
It is possible to reset all parameters to the factory default settings. The fieldbus address is not affected from the reset command.
Also the different maintenance counters are not affected but must be resetted manually at the UMC100-PAN.
The reset command can be activated via:
• UMC100-PAN
Resetting the password
The password can always be set or disabled using the UMC100 DTM (PBDTM) or using the UMC100-PAN.
Reading, setting and resetting maintenance counters
Preventive maintenance is the best way to ensure the long service life of any equipment.
The UMC provides several counters which help to better plan maintenance activities or to track down an existing problem.
• Number of motor starts can help to identify worn-out power contacts or to determine on contactor wear
• Number of protection trips
• Motor operation hours can help to assess the bearing status and its lubrication
The maintenance counters are available at the UMC100-PAN and in the PBDTM.
I/O-Module status codes
Three LEDs show the module status. The following table explains the status messages.
Status Explanation
Green LED Yellow LED Red LED
On On On Self-test during start-up
Flashing Off On Communication with UMC was interrupted. Relay outputs switched off.
Possible cause: Wiring between UMC and I/O module broken.
Possible corrective measure: Check wiring and check that the module was activated in the UMC
configuration.
Flashing Off Off Waiting for communication with UMC. Module is ready.
Possible cause: Wiring between UMC and I/O module broken.
Possible corrective measure: Check wiring and check that the module was activated in the UMC
configuration.
On Off Off Cyclic data exchange with UMC. No diagnosis.
On Flashing Off Cyclic data exchange with UMC. Diagnosis exists.
Irrelevant Flashing Hardware defect.
Possible corrective measure: Replace module.
Flashing
118
