UMC100.3 UNIVERSAL MOTOR CONTROLLER MANUAL
DX111-FBP.0
The DX111-FBP.0 expands the input and output channels of the UMC100.3.
It provides eight digital inputs for 24 V DC, four relay outputs and an analog output to drive an analogue instrument.
The following diagram shows the terminals and monitoring elements of the DX111-FBP.0 module.
DX122-FBP.0
The DX122-FBP.0 expands the input and output channels of the UMC.
It provides eight digital inputs 110 V AC - 230 V AC, four relay outputs and an analog output to drive an analog instrument.
The following figure shows the terminals and monitoring elements of the DX122-FBP.0 module.
Connecting terminals
for the digital inputs
Connecting terminals for
the analogue output.
Connecting terminals
for the relay outputs
Front label
Terminals
for the
24 V DC supply
Connecting terminals
for communication with
the UMC100
and further IO modules.
Connecting terminals
for the digital inputs.
LEDs
green READY = operation
yellow DIAG = warning
red ERROR = module fault
Terminals
for the
24 V DC supply
Connecting terminals
for communication with
the UMC100
and further IO modules.
Connecting terminals
for the digital inputs.
LEDs
green READY = operation
yellow DIAG = warning
red ERROR = module fault
Connecting terminals
for the digital inputs
Connecting terminals for the
analogue output.
Connecting terminals
for the relay outputs
Front label
