How to get started
There are many options for using the UMC100.3. Not all functions are required in all cases. Therefore the documentation
is split into separate parts. You only need to read the parts that are relevant for your application.
UMC100.3 Technical Manual
2CDC135032D0204
This is the main technical description and must always be read carefully before
using the UMC.
PBDTM
2CDC192012D02xx
1
This manual describes the configuration tool (Device Type Manager) that can be
used to configure and monitor the UMC100. It is based on the standardised FDT/
DTM technology. If you plan to only configure the UMC100 with the device de-
scription files like GSD (for PROFIBUS) or EDS (for CAN) or via the LCD panel, you
do not need to read this manual.
UMC100.3 Custom Application Editor
2CDC135034D02xx
1
This manual describes how to create customer-specific applications for the
UMC100.3. The Custom Application Editor is only required, if the logic built into
the UMC100.3 does not fulfill your needs. As the custom application
editor is part of the configuration tool (Device Type Manager), it is highly
recommended that you read the PBDTM manual first
Communication Interfaces
Whenever the UMC100.3 is to be connected to a fieldbus, read the appropriate
communication interface manual. Presently the following communication inter-
faces can be used together with UMC100.3:
PROFIBUS DP
DeviceNet
MODBUS RTU
Modbus TCP
PROFINET IO
EtherNet/IP
TM
PDP32.0
DNP31.0
MRP31.0
MTQ22-FBP.0
PNQ22-FBP.0
EIU32.0
1
1
1
1
1
2CDC135055D0201
1
1
representative, if you are unsure regarding the latest version.
You are now
reading this
manual
To Next Page
