Field mountable paperless recorder Appendix B – Modbus TCP/Modbus 485
158 IM/SM500F Rev. Z
B.6 Communications – Analog and Digital Inputs
Comms.
Digital
Inputs
Comms.
Analog
Inputs
Failure
Comms.
Analog Inputs
Comms.
Digital
Inputs
Comms.
Analog
Inputs
Failure
Comms.
Analog Inputs
Read/Write:
0 = Inactive
1 = Active
Floating point
(–999 to 9999)
Read/Write:
0 = Inactive
1 = Active
Floating point
(–999 to 9999)
Input
Number
Coil Number Coil Number Registers
Input
Number
Coil Number Coil Number Registers
1 0601 0651 0851 and 0852 13 0613 0663 0875 and 0876
2 0602 0652 0853 and 0854 14 0614 0664 0877 and 0878
3 0603 0653 0855 and 0856 15 0615 0665 0879 and 0880
4 0604 0654 0857 and 0858 16 0616 0666 0881 and 0882
5 0605 0655 0859 and 0860 17 0617 0667 0883 and 0884
6 0606 0656 0861 and 0862 18 0618 0668 0885 and 0886
7 0607 0657 0863 and 0864 19 0619 0669 0887 and 0888
8 0608 0658 0865 and 0866 20 0620 0670 0889 and 0890
9 0609 0659 0867 and 0868 21 0621 0671 0891 and 0892
10 0610 0660 0869 and 0870 22 0622 0672 0893 and 0894
11 0611 0661 0871 and 0872 23 0623 0673 0895 and 0896
12 0612 0662 0873 and 0874 24 0624 0674 0897 and 0898
Reserved 0625 to 0650 0675 to 0700 0899 to 1000
Table B.14 Modbus Inputs
