ABB TPU2000 User Manual

TPU2000/2000R Modbus/Modbus Plus Automation Guide
119
Register
Address
Item Description (Multiplier if any)
41696 5th Harmonic Phase C-Winding 1 Unsigned 16 Bit (X 2)
41697 All Harmonic Phase C-Winding 1 Unsigned 16 Bit (X 2)
41698 2nd Harmonic Phase A-Winding 2 Unsigned 16 Bit (X 2)
41699 5th Harmonic Phase A-Winding 2 Unsigned 16 Bit (X 2)
41700 All Harmonic Phase A-Winding 2 Unsigned 16 Bit (X 2)
41701 2nd Harmonic Phase B-Winding 2 Unsigned 16 Bit (X 2)
41702 5th Harmonic Phase B-Winding 2 Unsigned 16 Bit (X 2)
41703 All Harmonic Phase B-Winding 2 Unsigned 16 Bit (X 2)
41704 2nd Harmonic Phase C-Winding 2 Unsigned 16 Bit (X 2)
41705 5th Harmonic Phase C-Winding 2 Unsigned 16 Bit (X 2)
41706 All Harmonic Phase C-Winding 2 Unsigned 16 Bit (X 2)
41707 I restraint Phase A-Winding 1 (Ang) Unsigned 16 Bit
41708 I restraint Phase B-Winding 1 (Ang) Unsigned 16 Bit
41709 I restraint Phase C-Winding 1 (Ang) Unsigned 16 Bit
41710 I restraint Phase A-Winding 2 (Ang) Unsigned 16 Bit
41711 I restraint Phase B-Winding 2 (Ang) Unsigned 16 Bit
41712 I restraint Phase C-Winding 2 (Ang) Unsigned 16 Bit
41713 I Phase A-Winding 1 Unsigned 16 Bit (X 800)
41714 I PhaseB-Winding 1 Unsigned 16 Bit (X 800)
41715 I Phase C-Winding 1 Unsigned 16 Bit (X 800)
41716 I Neutral-Winding 1 Unsigned 16 Bit (X 800)
41717 I Phase A-Winding 2 Unsigned 16 Bit (X 800)
41718 I Phase B-Winding 2 Unsigned 16 Bit (X 800)
41719 I Phase C-Winding 2 Unsigned 16 Bit (X 800)
41720 I Neutral-Winding 2 Unsigned 16 Bit (X 800)
41721 Spare Unsigned 16 Bit
41722 I Phase A-Winding 1 (Ang) Unsigned 16 Bit
41723 I Phase B-Winding 1 (Ang) Unsigned 16 Bit
41724 I Phase C-Winding 1 (Ang) Unsigned 16 Bit
41725 I Neutral-Winding 1 (Ang) Unsigned 16 Bit
41726 I Phase A-Winding 2 (Ang) Unsigned 16 Bit
41727 I Phase B-Winding 2 (Ang) Unsigned 16 Bit
41728 I Phase C-Winding 2 (Ang) Unsigned 16 Bit
41729 I Neutral-Winding 2 (Ang) Unsigned 16 Bit
41730 I 0-1 – Zero Sequence Current
Winding 1
Unsigned 16 Bit (X 800)
41731 I 1-1 – Positive Sequence Current
Winding 1
Unsigned 16 Bit (X 800)
41732 I 2-1 – Negative Sequence Current
Winding 1
Unsigned 16 Bit (X 800)
41733 I 0-2 – Zero Sequence Current
Winding 2
Unsigned 16 Bit (X 800)
41734 I 1-2 – Positive Sequence Current
Winding 2
Unsigned 16 Bit (X 800)
41735 I 2-2 – Negative Sequence Current
Winding 2
Unsigned 16 Bit (X 800)
41736 I 0-1 (Ang) – Zero Sequence Angle
Winding 1
Unsigned 16 Bit
41737 I 1-1 (Ang) – Positive Sequence
Angle Winding 1
Unsigned 16 Bit
41738 I 2-1 (Ang) – Negative Sequence
Angle Winding 1
Unsigned 16 Bit
41739 I 0-2 (Ang) – Zero Sequence Angle
Winding 2
Unsigned 16 Bit
