ABB TPU2000 User Manual

TPU2000/2000R Modbus/Modbus Plus Automation Guide
59
Register
Address
Item Description
00009 TFA Trip Fail Alarm Energized
00010 51P-1 Winding 1 Phase Time Overcurrent Alarm Energized
00011 51P-2 Winding 2 Phase Time Overcurrent Alarm Energized
00012 50P-1 1
st
Winding 1 Phase Instantaneous Overcurrent Trip Alarm Energized
00013 150P-1 2
nd
Winding 1 Phase Instantaneous Overcurrent Trip Alarm Energized
00014 50P-2 1
st
Winding 2 Phase Instantaneous Overcurrent Trip Alarm Energized
00015 150P-2 2
nd
Winding 2 Phase Instantaneous Overcurrent Trip Alarm Energized
00016 51N-1 Winding 1 Neutral Time Overcurrent Trip Alarm Energized
00017 51N-2 Winding 1 Neutral Time Overcurrent Trip Alarm Energized
00018 50N-1 1
st
Winding 1 Neutral Instantaneous Overcurrent Trip Alarm Energized
00019 150N-1 2
nd
Winding 1 Neutral Instantaneous Overcurrent Trip Alarm Energized
00020 50N-2 1
st
Winding 2 Neutral Instantaneous Overcurrent Trip Alarm Energized
00021 150N-2 2
nd
Winding 2 Neutral Instantaneous Overcurrent Trip Alarm Energized
00022 46-1 Winding 1 Negative Sequence Time Overcurrent Trip Alarm Energized
00023 46-2 Winding 1 Negative Sequence Time Overcurrent Trip Alarm Energized
00024 87T-D Percentage Differential Disabled Alarm Energized
00025 87H-D High Set Instantaneous Function Disabled Alarm Energized
00026 51P-1D Winding 1 Phase Time Overcurrent Function Disabled Alarm
00027 51P-2D Winding 2 Phase Time Overcurrent Function Disabled Alarm
00028 51N-1D Winding 1 Neutral Time Overcurrent Function Disabled Alarm
00029 51N-2D Winding 2 Neutral Time Overcurrent Function Disabled Alarm
00030 50P-1D 1
st
Winding 1 Phase Instantaneous Overcurrent Function Disabled Alarm
00031 50P-2D 1
st
Winding 2 Phase Instantaneous Overcurrent Function Disabled Alarm
00032 50N-1D 1
st
Winding 1 Neutral Instantaneous Overcurrent Function Disabled Alarm
00033 50N-2D 1
st
Winding 2 Neutral Instantaneous Overcurrent Function Disabled Alarm
00034 150P-1D 2
nd
Winding 1 Phase Instantaneous Overcurrent Function Disabled Alarm
00035 150P-2D 2
nd
Winding 2 Phase Instantaneous Overcurrent Function Disabled Alarm
00036 150N-1D 2
nd
Winding 1 Neutral Instantaneous Overcurrent Function Disabled Alarm
00037 150N-2D 2
nd
Winding 2 Neutral Instantaneous Overcurrent Function Disabled Alarm
00038 46-1D Winding 1 Negative Sequence Time Overcurrent Function Disabled Alarm
00039 46-2D Winding 1 Negative Sequence Time Overcurrent Function Disabled Alarm
00040 PATA Phase A Target Alarm Energized
00041 PBTA Phase B Target Alarm Energized
00042 PCTA Phase C Target Alarm Energized
00043 PUA Pick Up Alarm Energized
00044 63 Sudden Pressure Input Alarm Energized
00045 THRUFA Through Fault Alarm Energized
00046 TFCA Through Fault Counter Alarm Energized
00047 TFKA-2 Through Fault KiloAmp Symmetrical Alarm Winding 2 Energized
00048 TFSCA Through Fault Summation Cycle Alarm Energized
00049 DTC Differential Trip Current Alarm Energized
00050 OCTC Overcurrent Trip Counter Alarm Energized
00051 PDA Phase Demand Current Alarm Energized
00052 NDA Neutral Demand Current Alarm Energized
00053 PRIM Primary Settings Alarm Energized
00054 ALT1 Alternate 1 Settings Enabled
00055
A
LT2
A
lternate 2 Settin
g
s Enabled
00056 STCA Settings Table Changed Alarm Energized
(L)
00057 87T Harmonic Restrained % Differential Trip Alarm Energized
(L)
00058 87H Unrestrained High Set Instantaneous Differential Trip Alarm Energized
(L)
00059 2HROA 2
nd
Harmonic Restraint Alarm Energized
(L)
00060 5HROA 5
th
Harmonic Restraint Alarm Energized
(L)
00061 AHROA All Harmonics Restraint Alarm (2
nd
through 11th Harmonic) Energized
(L)
00062 51P-1 Winding 1 Phase Time Overcurrent Alarm Energized
