TPU2000/2000R Modbus/Modbus Plus/ Modbus TCP/IP Automation Guide
60
Register
Address
Item Description
(L)
00063 51P-2 Winding 2 Phase Time Overcurrent Alarm Energized
(L)
00064 50P-1 1
st
Winding 1 Phase Instantaneous Overcurrent Trip Alarm Energized
(L)
00065 150P-1 2
nd
Winding 1 Phase Instantaneous Overcurrent Trip Alarm Energized
(L)
00066 50P-2 1
st
Winding 2 Phase Instantaneous Overcurrent Trip Alarm Energized
(L)
00067 150P-2 2
nd
Winding 2 Phase Instantaneous Overcurrent Trip Alarm Energized
(L)
00068 51N-1 Winding 1 Neutral Time Overcurrent Trip Alarm Energized
(L)
00069 51N-2 Winding 1 Neutral Time Overcurrent Trip Alarm Energized
(L)
00070 50N-1 1
st
Winding 1 Neutral Instantaneous Overcurrent Trip Alarm Energized
(L)
00071 150N-1 2
nd
Winding 1 Neutral Instantaneous Overcurrent Trip Alarm Energized
(L)
00072 50N-2 1
st
Winding 2 Neutral Instantaneous Overcurrent Trip Alarm Energized
(L)
00073 150N-2 2
nd
Winding 2 Neutral Instantaneous Overcurrent Trip Alarm Energized
(L)
00074 46-1 Winding 1 Negative Sequence Time Overcurrent Trip Alarm Energized
(L)
00075 46-2 Winding 1 Negative Sequence Time Overcurrent Trip Alarm Energized
(L)
00076 63 Sudden Pressure Seal In Alarm Energized
00077 ULO 1 User Logical Output 1
00078 ULO 2 User Logical Output 2
00079 ULO 3 User Logical Output 3
00080 ULO 4 User Logical Output 4
00081 ULO 5 User Logical Output 5
00082 ULO 6 User Logical Output 6
00083 ULO 7 User Logical Output 7
00084 ULO 8 User Logical Output 8
00085 ULO 9 User Logical Output 9
00086 LOAD
Load Current Alarm Ener
ized
00087 OCA-1 Winding 1 Overcurrent Alarm Energized
00088 OCA-2 Winding 2 Overcurrent Alarm Energized
00089 HLDA-1 Winding 1 High Level Detector Alarm
00090 LLDA-1 Winding 1 Low Level Detector Alarm
00091 HLDA-2 Winding 2 High Level Detector Alarm
00092 LLDA-1 Winding 1 Low Level Detector Alarm
00093 HPFA High Power Factor Alarm Energized
00094 LPFA Low Power Factor Alarm Energized
00095 VarDA 3 Phase kVar Demand Alarm Energized
00096 PVarA Positive 3 Phase kVar Alarm Energized
00097 NVarA Negative 3 Phase kVar Alarm Energized
00098 PWatt1 Pwinding 1 Positive 3 Phase kWatt Alarm Energized
00099 Pwatt2 Pwinding 2 Positive 3 Phase kWatt Alarm Energized
3 00100 Reserved Reserved
3 00101 Reserved Reserved
3 00102 Reserved Reserved
3 00103 Reserved Reserved
3 00104 Reserved Reserved
3 00105 Reserved Reserved
3 00106 Reserved Reserved
3 00107 Reserved Reserved
3 00108 Reserved Reserved
3 00109 Reserved Reserved
3 00110 Reserved Reserved
3 00111 Reserved Reserved
3 00112 Reserved Reserved
3 00113 Reserved Reserved
3 00114 Reserved Reserved
3 00115 Reserved Reserved
To Next Page
