TTF300 FIELD-MOUNT TEMPERATURE TRANSMITTER | OI/TTF300-EN REV. I 19
CSA Intrinsically Safe
Model TTF300-R1H
Up to HW-Rev.: 01.07
Control Drawing
SAP_214825
Model TTF300-R1P
Control Drawing
TTF300-R1..P (IS)
Model TTF300-R1F
Control Drawing
TTF300-R1..F (IS)
Class I, Div. 1 + 2, Groups A, B, C, D
Class I, Zone 0, Ex ia IIC
CSA Non-Incendive
Model TTF300
-R2H
Up to HW-Rev.: 01.07
Control Drawing
SAP_214827 (NI_PS)
SAP_214895 (NI_AA)
Model TTF300-R2P
Control Drawing
TTF300-
R2..P (NI_PS)
TTF300-R2..P (NI_AA)
Model TTF300
-R2F
Control Drawing
TTF300-
R2..F (NI_PS)
TTF300-R2..F (NI_AA)
Class I, Div. 2, Groups A, B, C, D
CSA Explosion proof
Model TTF300-R3
XP, DIP Class I, II, III, Div. 1 + 2, Groups A-G, factory sealed
CSA Explosion Proof and Intrinsically Safe
Model TTF300
-R7H (R1H + R3H)
Up to
HW-Rev.: 01.07
Control Drawing
SAP_214825
Model TTF300-R7P (R1P + R3P)
Control Drawing
TTF300-R1..P (IS)
Model TTF300
-R7F (R1F + R3F)
Control Drawing
TTF300-
R1..F (IS)
XP, DIP Class I, II, III, Div. 1 + 2, Groups A
-G, factory sealed
Class I,
Div. 1 + 2, Groups A, B, C, D
Class I, Zone 0, Ex ia IIC
LCD indicator Ex marking
FM Intrinsically Safe
Control Drawing
SAP_214 748
I.S. Class I Div 1 and Div 2, Group: A, B, C, D or
I.S. Class I Zone 0 AEx ia IIC T*
U
i
/ V
max
= 9 V, I
i
/ I
max
< 65.2 mA, P
i
= 101 mW, C
i
= 0.4 μF, L
i
= 0
FM Non-Incendive
Control Drawing
SAP_214 751
N.I. Class I Div 2, Group: A, B, C, D or Ex nL IIC T**, Class I Zone 2
U
i
/ V
max
= 9 V, I
i
/ I
max
< 65.2 mA, P
i
= 101 mW, C
i
= 0.4 μF, L
i
= 0
CSA Intrinsically Safe
Control Drawing
SAP_214 749
I.S. Class I Div 1 and Div 2; Group: A, B, C, D or
I.S Zone 0 Ex ia IIC T*
U
i
/ V
max
= 9 V, I
i
/ I
max
< 65.2 mA, P
i
= 101 mW, C
i
< 0.4 μF, L
i
= 0
CSA Non-Incendive
Control Drawing
SAP_214 750
N.I. Class I Div 2, Group: A, B, C, D or Ex nL IIC T**, Class I Zone 2
U
i
/ V
max
= 9 V, I
i
/ I
max
< 65.2 mA, P
i
= 101 mW, C
i
< 0.4 μF, L
i
= 0
* Temp. Ident: T6 T
amb
56 °C, T4 T
amb
85 °C
** Temp. Ident: T6 T
amb
60 °C, T4 T
amb
85 °C
