ABB TTF300 User Manual

60 TTF300 FIELD-MOUNT TEMPERATURE TRANSMITTER | OI/TTF300-EN REV. I
… 10 Operation
Parameter overview HART® (for HART-devices from SW-Rev.: 03.00)
Note
This overview of parameters shows all the menus and parameters available on the device.Depending on the version and configuration
of the device, not all of the menus and parameters may be visible in it.
Devices to SW-Rev.: 01.03 and from SW-Rev.: 03.00 have partly different menus and parameters.The options for showing process
variables are increased from SW-Rev.: 03.00. Additional device and diagnostic information is provided.The setting and canceling of
write protection has changed.
In addition, for devices from SW-Rev.: 03.00, additional information (event and configuration monitor, see HART interface
description, COM/TTX300/HART) and detailed diagnostics can be displayed and configured in Tools / Drivers, such as FIM and DTM.
Easy Setup
1
Language
HART Tag
HART Long Tag
Sensortype S1
R
-Connection S1
2
-wire Resistance S1
Thermocouple CJC 1
Ext. CJC Temperature 1
Sensortype S2
R
-Connection S2
2
-wire Resistance S2
Thermocouple CJC 2
Ext. CJC
Temperature 2
Input / output assignment
PV Unit
PV Lower Range Value
PV Upper Range Value
PV Damping
