Need help?Do you have a question about the ABB TTF300 and is the answer not in the manual?
General| Brand | ABB |
|---|---|
| Model | TTF300 |
| Category | Transmitter |
| Language | English |
General guidance and instructions for safe product use and installation.
Explanation of warning symbols (DANGER, WARNING, CAUTION, NOTICE) and their meanings.
Defines the intended applications for the device, specifying its primary functions.
Details instances considered as improper use of the device.
Information regarding warranty terms and conditions.
Disclaimer concerning the operator's responsibility for network security.
Information on downloading the latest software and security updates.
Details the explosion protection marking for ATEX and IECEx certifications.
Specific ATEX intrinsic safety markings for the transmitter.
Details ATEX markings for increased safety and dust explosion protection.
Details ATEX marking for flameproof (enclosure) type of protection.
Details combined ATEX flameproof and intrinsic safety markings.
Details IECEx marking for flameproof (enclosure) type of protection.
Details ATEX intrinsic safety markings for the LCD indicator.
Details IECEx intrinsic safety markings for the transmitter and LCD indicator.
Details IECEx dust explosion protection markings.
Electrical data for intrinsic safety type of protection Ex ia IIC (Part 1) for the transmitter.
Electrical data for intrinsic safety type of protection Ex ia IIC (Part 2) for the LCD indicator.
Electrical data for intrinsic safety type of protection Ex ia IIC (Part 2) for transmitters.
Electrical data for flameproof (enclosure) type of protection Ex db IIC.
Electrical data for dust explosion protection (Ex tb IIIC T135°C Db, Ex tc IIIC T135°C Dc).
Electrical data for intrinsic safety type of protection Ex ia IIC (Part 3) for LCD indicator interface.
Electrical data for intrinsic safety type of protection Ex ia IIC for LCD indicator.
Instructions for installation, commissioning, and maintenance in potentially explosive atmospheres.
Guidelines for using cable entries with 'Ex d' protection, with and without cable glands.
Specific instructions for installing cable glands, including temperature and torque.
Maintenance checks for cable glands and installation torque.
Grounding requirements for intrinsically safe circuits in explosive atmospheres.
Procedures for proving intrinsic safety and the conditions for fulfillment.
Diagram and instructions for hookup in ATEX Zone 0 for intrinsic safety.
Diagram and instructions for hookup in ATEX Zone 1 (0) for intrinsic safety.
Diagram and instructions for hookup in ATEX Zone 1 (20) for intrinsic safety.
Guidelines for installation and operation in ATEX Zone 2 and Zone 22.
Installation points for HART TTF300 from HW-Rev. 02.00, including fuse requirements.
Hookup diagram and guidelines for dust explosion protection in Zone 21.
Hookup for Zone 0/21 with dust explosion protection, detailing sensor and transmitter approval.
Hookup for Zone 1 with flameproof (enclosure) protection, detailing component approval.
General requirements for connecting transmitters and cable entries in explosive atmospheres.
Commissioning and parameterization in explosive atmospheres using terminals or modems.
Details cFMus explosion protection markings for the transmitter (Intrinsically Safe, Non-Incendive, Explosion Proof).
Details FM/CSA explosion protection markings (Intrinsically Safe, Non-Incendive, Explosion Proof).
Details explosion protection markings for the LCD indicator for cFMus, FM, and CSA.
General installation, grounding, and material compatibility notes for explosive atmospheres.
Notes on thread damage and use of devices with damaged threads for XP protection.
Precautions against electrostatic charging of device surfaces in hazardous areas.
Safety warnings regarding improper repair and flameproof joint repairs.
Details sensor input capabilities, including redundancy and drift monitoring.
Explains the two-sensor input for enhanced system availability and redundancy behavior.
Details output behavior and diagnostic messages for Increased Availability, Safety, and Accuracy.
Enables monitoring of sensor deviation and its diagnostic response.
Allows individual sensor error adjustment using CVD coefficients for maximum accuracy.
Explanation of information found on the device's name plates for HART, PROFIBUS PA, and FOUNDATION Fieldbus.
Details the additional plates for explosion-proof devices with a single type of protection.
Explains markings for devices with multiple explosion protection types (e.g., intrinsic safety and flameproof).
Procedures for inspecting devices for damage after transport.
Instructions for packing and transporting the device to prevent damage.
Guidelines for storing the device in its original packaging under appropriate ambient conditions.
Instructions for packaging, filling out return forms, and shipping devices for repair.
Specifies standard and optional ambient temperature ranges for installation.
Instructions for wall and pipe mounting of the transmitter, including safety.
Safety procedures for opening and closing the transmitter housing, especially in explosive atmospheres.
Instructions for adjusting the position of the LCD indicator for optimal viewing.
Safety instructions and guidelines for electrical connections, including wiring and insulation.
Measures to protect the transmitter from damage due to overvoltage, overcurrent, and high-frequency signals.
Specifications for power supply cable outer diameter and wire cross-section.
Requirements for cable glands to maintain IP rating and for different cable diameters.
Ensuring electromagnetic interference immunity by shielding sensor and power supply cables.
Guidelines for grounding sensor and power supply cables for optimal immunity and safety.
Provides additional examples of shielding and grounding configurations for sensor and power supply cables.
Shielding example for insulated sensor with ungrounded transmitter housing.
Shielding example for non-insulated sensor with grounded transmitter housing.
Diagrams showing terminal assignments for resistance thermometers and resistors.
Diagrams showing terminal assignments for thermocouples, voltages, and RTD combinations.
Detailed instructions for connecting the sensor cable to the transmitter terminals.
Safety instructions for electrical connections, emphasizing authorized personnel and safe isolation.
Measures to protect the transmitter from damage due to overvoltage, overcurrent, and high-frequency signals.
Specifications for power supply cable outer diameter and wire cross-section.
Requirements for cable glands to maintain IP rating and for different cable diameters.
Ensuring electromagnetic interference immunity by shielding sensor and power supply cables.
Guidelines for grounding sensor and power supply cables for optimal immunity and safety.
Provides additional examples of shielding and grounding configurations for sensor and power supply cables.
Diagrams showing terminal assignments for resistance thermometers and resistors.
Diagrams showing terminal assignments for thermocouples, voltages, and RTD combinations.
Detailed instructions for connecting the sensor cable to the transmitter terminals.
Details electrical data for resistance thermometer inputs and thermocouple/voltage inputs.
Details transmission behavior, output signal, and error current for HART protocol.
Details output signal, error current, and block structure for PROFIBUS PA protocol.
Details output signal, error current, and block structure for FOUNDATION Fieldbus protocol.
Details power supply technology, voltage, and ripple for HART and general applications.
Specifies supply voltage and current consumption for PROFIBUS PA and FOUNDATION Fieldbus.
Conditions for standard application with 4-20mA functionality, including voltage drop.
Conditions for standard HART functionality, including minimum supply voltage and resistance.
General overview of transmitter readiness after installation and connection checks.
Essential checks before commissioning the device, including wiring and ambient conditions.
Details HART communication protocols, modes, and configuration options.
Details PROFIBUS PA/FOUNDATION Fieldbus communication, interface, and voltage/current consumption.
Details FOUNDATION Fieldbus communication, interface, and voltage/current consumption.
Describes configuration types via DTM, EDD, FDI, and LCD indicator.
Safety instructions to prevent unintended startup and ensure safe operation.
Details hardware settings and DIP switch functions for HART and PROFIBUS PA devices.
Explains how to navigate the LCD display menus and use the control buttons.
Describes HART menu levels (Information, Process, Configuration) and their functions.
Describes menu levels (Information, Process, Configuration) for PROFIBUS PA and FOUNDATION Fieldbus.
Explains the process display on the LCD, including symbols and value display options.
Details HART error messages, device status symbols, and NAMUR classification.
Details error messages for PROFIBUS PA/FOUNDATION Fieldbus, including symbols and NAMUR classification.
Instructions for switching to the information level to view diagnostic information.
Instructions for switching to the configuration level to display and change parameters.
Guides on selecting and changing parameters via table entry, numerical, or alphanumeric input.
Overview of HART menus and parameters for devices up to SW-Rev. 01.03.
Overview of HART menus and parameters for Calibrate and Diagnosis sections.
Detailed description of HART parameters within the Device Setup menu for SW-Rev. 01.03.
Detailed description of HART parameters for R-Connection and Measured Range for SW-Rev. 01.03.
Description of parameters available in the Device Info menu.
Description of parameters for Language, Contrast, and display views.
Description of parameters related to fault signaling and process alarms.
Description of parameters for HART Tag, Address, Burstmode, and Response Preambles.
Description of parameters for Measured Range and Analog Out (Trim).
Description of parameters for Looptest, Device status, Temp. of Electronics, and sensor data.
Steps to activate write protection for the device configuration.
Steps to deactivate write protection using an entry combination.
Overview of HART parameters under Easy Setup for SW-Rev. 03.00.
Overview of HART parameters for Device Setup, Display, Process Alarm, and Communication.
Overview of HART parameters for Calibrate, Diagnosis, Device Info, and Service.
Detailed description of HART parameters in Easy Setup for Sensor Type S1.
Detailed description of HART parameters in Easy Setup for Sensor Type S2.
Detailed description of HART parameters for R-Connection, Resistance, and CJC in Easy Setup.
Description of HART parameters in Device Setup for SW-Rev. 03.00.
Description of HART parameters for Input/PV Unit in Device Setup for SW-Rev. 03.00.
Description of HART parameters for Language, Contrast, and display views.
Description of HART parameters for Process Alarm and Reaction on errors.
Description of HART parameters for Tag, Address, Burstmode, and Revision.
Description of HART parameters for Measured Range and Analog Out.
Description of HART parameters for Looptest, Device status, Temp. of Electronics, and sensor data.
Description of HART parameters for Device Type, Serial Number, Software/Hardware Version, HART Tag.
Description of HART parameters for Factory Reset, Reset to Order, Device Reset, and Key Value.
Configuration and management of regular and advanced software write protection.
Overview of Device Setup parameters for PROFIBUS PA and FOUNDATION Fieldbus.
Overview of Device Setup parameters for PROFIBUS PA and FOUNDATION Fieldbus.
Overview of Device Info parameters for PROFIBUS PA and FOUNDATION Fieldbus.
Overview of Communication parameters for PROFIBUS PA and FOUNDATION Fieldbus.
Overview of Service parameters for PROFIBUS PA and FOUNDATION Fieldbus.
Overview of Display parameters for Language, Contrast, and Operator Pages.
Overview of Calibration parameters, including Reset Device and Reset with Defaults.
Description of Device Setup parameters for Sensor Type selection.
Description of Device Setup parameters for R-Connection, CJC, and External Temperature.
Description of parameters in the Device Info menu.
Description of parameters for TAG, Bus Address, and Ident Number.
Description of Service Menu parameters for Device Temperature, Sensor data, and Communication.
Description of Display Menu parameters for Language, Contrast, Operator Pages, and Line views.
Description of Calibrate Menu parameters for Reset Device and Reset with Defaults.
Details factory settings for HART, PROFIBUS PA, and FOUNDATION Fieldbus devices.
Monitoring of operating data, including supply voltage, loop current, and sensor readings.
Tracks total and categorized operating hours of the transmitter.
Procedure to view detailed error messages and remedy information on the display.
Lists possible HART error messages, device status, cause, and remedy for SW-Rev. 01.03.
Lists additional possible HART error messages, device status, cause, and remedy.
Lists possible HART error messages, device status, cause, and remedy for SW-Rev. 03.00.
Lists possible error messages for PROFIBUS PA/FOUNDATION Fieldbus, including status, cause, and remedy.
Safety instructions regarding improper repair and authorized personnel for maintenance.
Instructions for cleaning the exterior of the device, considering housing and gasket compatibility.
Safety warnings regarding improper repair, authorized personnel, and flameproof joints.
Instructions for packaging, filling out return forms, and shipping devices for repair.
Notes regarding disposal of products marked with the symbol, not as unsorted municipal waste.
Information on where to find the device data sheet.
Information on where to find Declarations of Conformity and ATEX-certified device documents.
Form for detailing device contamination and substances contacted for return shipments.
