TTF300 FIELD-MOUNT TEMPERATURE TRANSMITTER | OI/TTF300-EN REV. I 49
The error can then be read in plain text via the “Diagnosis”
information level (from SW-Rev.: 03.00).
Additionally, the diagnostic messages are divided into the
following areas:
Range
Description
Electronics
Diagnosis for device hardware.
Sensor
Diagnosis for sensor elements and
connection
lines.
Configuration
Diagnosis of the communication interface and
parameterization / configuration.
Operating conditions
Diagnosis for ambient and process conditions.
Process
(from SW-Rev.: 03.00)
Notes and warnings when leaving the
sensor or
process temperature range.
Note
For a detailed description of the errors and notices on
troubleshooting, see Diagnosis / error messages on page 81.
Error messages in the PROFIBUS PA® and
FOUNDATION Fieldbus® LCD display
In the event of an error, a message consisting of a symbol and
text appears at the bottom of the process screen
(e. g. electronics)The text displayed provides information about
the area in which the error has occurred.
Process display
Elektronik
The error messages are divided into four groups in accordance
with the NAMUR classification scheme.The group assignment
can only be changed using a DTM or EDD:
Symbol
Description
Error
/ failure
Check function
Outside of the specification
Maintenance required
The error can then be read in plain-text format on the ‘Diagnosis’
information level.
The error messages are also divided into the following areas:
Range
Description
Electronics
Diagnosis for device hardware.
Sensor
Diagnosis for sensor elements and
connection
lines.
Installation / Configuration
Diagnosis for communication interface and
parameterization / configuration
Operating conditions
Diagnosis for ambient and process conditions.
Note
For a detailed description of the errors and notices on
troubleshooting, see Possible error messages – PROFIBUS PA®
and FOUNDATION Fieldbus® on page 86.
