52 TTF300 FIELD-MOUNT TEMPERATURE TRANSMITTER | OI/TTF300-EN REV. I
… 10 Operation
Parameter overview HART® (for devices to SW-Rev.: 01.03)
Note
This overview of parameters shows all the menus and parameters available on the device.Depending on the version and configuration
of the device, not all of the menus and parameters may be visible in it.
Devices to SW-Rev.: 01.03 and from SW-Rev.: 03.00 have partly different menus and parameters.The options for showing process
variables are increased from SW-Rev.: 03.00. Additional device and diagnostic information is provided.The setting and canceling of
write protection has changed.
In addition, for devices from SW-Rev.: 03.00, additional information (event and configuration monitor, see HART interface
description, COM/TTX300/HART) and detailed diagnostics can be displayed and configured in Tools / Drivers, such as FIM and DTM.
Device Setup
1
Write protection
Input Sensor 1
Sensor Type
R
-Connection
2
-wire Resistance
Thermocouple RJ
ext. Thermocouple RJ
Input Sensor 2
Input / output assignment
Measured range
Engeneering Unit
Measured Range Begin
Measured Range End
Damping
Factory reset
Device Info
2
Device Type
Serial Number
Software Version
Hardware Version
HART Tag
HART Descriptor
Operation Time
Display
3
Display Value
Bargraph
Bargraph View
Language
Contrast
Process Alarm
4
Fault signaling
Communication
5
HART Tag
Address (Multidrop)
HART Burstmode
HART Resp. Preambles
