54 TTF300 FIELD-MOUNT TEMPERATURE TRANSMITTER | OI/TTF300-EN REV. I
… 10 Operation
Parameter description HART® (for HART®-devices to SW-Rev.: 01.03)
Menu: Device Setup
Menu / parameter
Description
… / Device Setup
Write protection
Activates write protection for the entire device
•
Yes: locked
Input combination:≠ 0110
•
No: unlocked
Input combination:0110
Input Sensor 1
Select the ‘Input Sensor 1’ submenu.
Input Sensor 2
Select the ‘Input Sensor 2’ submenu.
Input / output assignment
Input / output assignment selects the inputs that are mapped to the current output
•
Sensor 1
•
Sensor 2
•
Difference (S1-S2)
•
Difference (S2-S1)
•
Meanvalue
•
Electr. Meas. S1
•
Electr. Meas. S2
•
Redundancy
• Temp. Electronics
Measured range
Select the ‘Measured range’ submenu.
Damping
Configurable τ 63% output signal damping value
Value range:0 to 100 s
Factory reset
Resets configuration data, adjustment data trim high / low and DAC adjustment values to
factory settings.
• Yes / OK
… / Device Setup / Input Sensor 1
… / Device Setup / Input Sensor 2
Sensor Type
Selects sensor type:
•
Pt100 (IEC751):Pt100 resistance thermometer (IEC 751)
•
Pt1000 (IEC751):Pt1000 resistance thermometer (IEC 751)
•
Type K TC (IEC584):Thermocouple type K (IEC 584)
•
Type B TC (IEC584):Thermocouple type B (IEC 584)
•
Type C TC (ASTME988):Type C thermocouple (IEC584)
•
Type D TC (ASTME988):Thermocouple type D (ASTME 988)
•
Type E TC (IEC584):Thermocouple type E (IEC 584)
•
Type J TC (IEC584):Type J thermocouple (IEC584)
•
Type N TC (IEC584):Thermocouple type N (IEC 584)
•
Type R TC (IEC584):Type R thermocouple (IEC584)
•
Type S TC (IEC584):Type S thermocouple (IEC584)
•
Type T TC (IEC584):Type T thermocouple (IEC584)
•
Type L TC (DIN43710):Type L thermocouple (DIN43710)
• Type U TC (DIN43710):Type U thermocouple (DIN43710)
