6 TTF300 FIELD-MOUNT TEMPERATURE TRANSMITTER | OI/TTF300-EN REV. I
2 Use in potentially explosive atmospheres in accordance with ATEX and IECEx
Ex marking
Note
• Further information on the approval of devices for use in potentially explosive atmospheres can be found in the explosion
protection test certificates (at www.abb.com/temperature).
• Depending on the design, a specific marking in accordance with ATEX or IECEx applies.
• A list of standards, including the output data to which the device conforms, can be found in the examination certificate or
manufacturer’s declaration supplied with the device.
• In devices with several types of protection, for example TTF300-E4, observe the ‘Product Identification’ chapter in the operating
or commissioning instruction before commissioning.
Transmitter
ATEX intrinsic safety
The device fulfills the requirements of Directive 2014/34/EU in
case of corresponding purchase orders and is approved for use
in Zone 0, 1 and 2.
Model TTF300-E1H
To
HW-Rev.: 01.07:
Type Examination Test Certificate
From
HW-Rev.: 02.00:
Type Examination Test Certificate
PTB 05 ATEX 2017 X
PTB 20 ATEX 2008 X
Model TTF300
-E1P and TTF300-E1F
Type Examination Test Certificate
PTB 09 ATEX 2016 X
II 1 G
Ex ia IIC T6…T1 Ga
II 2 (1) G
Ex [ia IIC Ga] ib IIC T6…T1 Gb
II 2 G (1D) Ex [ia IIIC Da] ib IIC T6…T1 Gb
ATEX increased safety and dust explosion protection
Approved for use in zone 2 and 22.
Model TTF300-E5
TTF300-E5H to HW-Rev.: 01.07, TTF300-E5P, TTF300-E5F:
Manufacturer’s Declaration
II 3 G
Ex ec IIC T6...T1 Gc
II 3 D
Ex tc IIIB T133°C Dc
ATEX dust explosion protection
Approved for use in Zone 21 and 22.
TTF300-D5H model to HW-Rev.: 01.07
Type Examination Test Certificate
BVS 06 ATEX E 029
II 2D
Ex tb IIIC T135°C Db
II 3D
Ex tc IIIC T135°C Dc
ATEX dust explosion protection | intrinsic safety
Permitted for zone 21, 22 | Zone 0, 1 and 2.
The ‘D6H’ coding combines ‘Dust explosion protection’ (TTF300-
D5H) and ‘Intrinsic safety’ (TTF300-E1H) types of protection.
Devices with several types of protection may only be operated in
one of the possible types of protection. For this purpose,
observe the ‘Product Identification’ chapter in the operating or
commissioning instruction before commissioning.
TTF300-D6H model to HW-Rev.: 01.07
Type examination test certificate
“Dust explosion protection”, (TTF300-D5H)
BVS 06 ATEX E 029
Type examination certificate
“Intrinsic safety”, (TTF300
-E1H)
PTB 05 ATEX 2017 X
II 1G
Ex ia IIC T6…T1 Ga
II 2D Ex tb IIIC T135°C Db
ATEX flameproof (enclosure)
Approved for use in Zone 1 and 2.
Model TTF300-E3
Type Examination Test Certificate
PTB 99 ATEX 1144 X
II 1/2 G
Ex db IIC T6/T4 Ga/Gb
