46 TTF300 FIELD-MOUNT TEMPERATURE TRANSMITTER | OI/TTF300-EN REV. I
… 10 Operation
HART® menu levels
To SW-Rev.: 01.03
Process display
Configuration level
Device Setup
Device Info
Display
Process Alarm
Communication
Calibrate
Diagnosis
From SW-Rev.: 03.00
Process display
Information level with
operator menu
Configuration level
Diagnosis
Easy Setup
Operator Page 1 Device Setup
Signal View
Display
Process Alarm
Communication
Calibrate
Diagnosis
Device Info
Service
Process display
The process display shows the current process values.
Operator menu
On the information level, the operator menu can be used to display diagnostic information and choose which operator pages to
display.
Configuration level
The configuration level contains all the parameters required for device commissioning and configuration.The device configuration
can be changed on this level.
Commissioning
The menu item “Easy Setup” from SW-Rev.: 03.00 enables a simplified configuration of the device.
