ABB TTF300 User Manual

TTF300 FIELD-MOUNT TEMPERATURE TRANSMITTER | OI/TTF300-EN REV. I 83
Possible error messages – HART® devices to SW-Rev.: 01.03
Range
Displays the
device
status
Displays the
DIAG.NO.
Cause
Remedy
Electronics
F
1
Device defective
Replace the device
Electronics
S
2
Ambient temperature overshot
/ undershot
Check
environment; reposition measuring point if
required
Electronics
F
3
EEPROM defective
Replace the device
Electronics
M
4
Electronics overload
Factory reset
Electronics
F
5
Memory error
Factory reset
Electronics
I
7
LCD display connected
Remove display
Installation / Configuration
I
8
Device write
-protected
Remove write protection
Electronics
I
9
EEPROM busy
Wait for status information to finish processing
Electronics
F
12
Sensor input defective (communication)
Replace the device
Electronics
F
13
Sensor input defective (error)
Replace the device
Electronics
F
14
Sensor input defective (ADC error)
Replace the device
Installation / Configuration
C
32
Simulation mode
Exit simulation mode
Sensor
F
34
Measuring error,
sensor 1
Check sensor connection
Sensor
F
35
Short-circuit, sensor 1
Check sensor connection
Sensor
F
36
Wire break, sensor
1
Check sensor connection
Sensor
F
37
Range exceeded, sensor 1
Check measuring limits
Sensor
F
38
Range undershot,
sensor 1
Check measuring limits
Installation / Configuration
I
41
Single-point adjustment active, sensor 1
Terminate single-point adjustment
Installation / Configuration
I
42
Two
-point adjustment active, sensor 1
Terminate two
-point adjustment
Sensor
F
50
Measuring error, sensor 2
Check sensor connection
Sensor
F
51
Short
-circuit, sensor 2
Check sensor connection
Sensor
F
52
Wire break, sensor 2
Check sensor connection
Sensor
F
53
Range exceeded, sensor
2
Check measuring limits
Sensor
F
54
Range undershot, sensor 2
Check measuring limits
Installation / Configuration
F
65
Configuration defective
Check configuration:
A
Wrong device
B
Measuring span is too small
C
Incorrect configuration data
