2 - Characteristics
Characteristics and technical data
UNO-2.0-TL-OUTD UNO-3.0-TL-OUTD
Input
Absolute Maximum Input Voltage (Vmax,abs) 600 V
Input start-up voltage (Vstart) 100...300 V (default 150 V)
Input operating interval (Vdcmin...Vdcmax) 0.7xVstart...580 V (min 80V)
Rated Input Voltage (Vdcr) 400 V
Input Nominal Power(Pdcr) 2200 W 3200 W
Number of Independent MPPT 1
Maximum input power
(PMPPTmax)
2200 W 3200 W
DC Voltage MPPT Interval
(VMPPTmin ... VMPPTmax) to Pacr
180...500 V 200...500 V
Maximum DC Input Current (Idcmax) 12.5 A 16.0 A
Maximum Return current (AC side vs DC side) < 5 mA
(3)
Maximum short circuit current (Iscmax) 15.0 A 20.0 A
Number of DC Connection Pairs in Input 1
Type of Input DC Connectors Quick-t PV connector
(4)
Type of photovoltaic panels that can be connected
at input according to IEC 61730
Class A
Input protection
Reverse Polarity Protection Yes, from current limited source
Input overvoltage protection
- Varistors
Yes
Insulation Check Complying with the local standard
Characteristics of DC disconnect switch (Version
-S)
Max. 25 A / 600 V
Output
AC Connection to the grid Single phase
Nominal Output Power (Pacr @cosφ=1) 2000 W 3000 W
Maximum Output Power (Pacmax @cosφ=1) 2000 W 3000 W
Maximum apparent Output power (Smax) 2000 VA 3000 VA
Rated AC Output Voltage (Vacr) 230 V
Output voltage range (Vacmin...Vacmin) 180...264 V
(1)
Maximum output current (Iacmax) 10.0 A 15.0 A
Maximum fault current 18.3 A rms (200ms)
Contribution to short-circuit current 12.0 A 17.0 A
Inrush current Negligible
Rated Output Frequency (fr) 50 / 60 Hz
Output Frequency Range (fmin...fmax) 47...53 Hz / 57…63 Hz
(2)
Nominal power factor
and setting interval
> 0.995
adj. ± 0.8 at maximum Smax
Total Current Harmonic Distortion <3%
AC Connections Type Female connector from panel
Output protection
Anti-islanding Protection Complying with the local standard
Maximum AC overcurrent protection 16.0 A 20.0 A
Output overvoltage protection - Varistors 2 (L - N / L - PE)
Operating performance
Maximum Efciency (ηmax) 97.3%
Weighted Efciency (EURO/CEC) 96.0% / -
Power Supply Threshold 8.0 W
Night-time consumption < 0.1W
